Before installing this product, please make sure you got the right part for your bike. See the
part number on the packaging and use the Product Advisor on our website to check
compatibility.
These instructions are applicable to a wide range of motorcycles and describe the main
install steps needed for a successful installation.
You can find motorcycle specific Supplementary Manuals on our website. Please visit:
www.healtech-electronics.com/XTRE
Disclaimer: Do not attempt to install the product if you don't have basic mechanical skills.
HealTech Electronics Ltd. and its distributors shall not be liable for any loss or damage
caused by improper installation. If in doubt, please consult with your dealer.
1. Installation
1.
Check the supplied parts:
X-TRE Power Box (with Velcro strips)
-
Wiring harness
-
Yellow butt connectors, gel-filled (2 pcs)
-
Red tap connector, gel-filled
-
4p jumper-plug
-
Cable ties (2+1 pcs), HealTech stickers (2+2 pcs)
-
2.
Make sure the ignition key is in OFF position. Remove the seat.
3.
Locate the ECM (Engine Control Module).
4.
Locate the Black wire with thin dark Green stripe (B/G), in the ECM
connector. The wire position for different models is as follows:
DL-1000
(2019-2020)
GSX-R600
GSX-R750
GSX-R1000
GSX-S750
GSX-S1000
SFV400 / SFV650 / Gladius
(2009-2015)
Boulevard C90 / Intruder
C1500 / VL1500
Boulevard C50 / Intruder
C800 / VL800
ALL other years and models
XT-S0x_Manual_en.pdf
http://www.healtech-electronics.com
X-TRE Power Box
Installation and Operation Manual
for XT-S01 and XT-S02
(2008-2017)
(2008-2017)
(2007-2017)
(2015-2021)
(2015-2021)
(2013-2017)
(2009-2017)
[rev. 011]
Black connector, pin no. 23
Middle row, 2
nd
terminal from left to right
at the back (wire) side of the connector
Large connector, pin no. 31
Bottom row, 4
th
terminal from left to right
at the back (wire) side of the connector
Black / Large connector, pin no. 6
Top row, 6
th
terminal from right to left at
the back (wire) side of the connector
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Healtech X-TRE Power Box
Summary of Contents for Healtech X-TRE Power Box
- Page 1 Disclaimer: Do not attempt to install the product if you don’t have basic mechanical skills. HealTech Electronics Ltd. and its distributors shall not be liable for any loss or damage caused by improper installation. If in doubt, please consult with your dealer.
- Page 2 Peel off about 2 cm (0.8”) from the black sleeve (tape) around the wires. You may disconnect the ECM plug to have more space around the wires. Cut the B/G wire, about 4 cm (1.6”) away from the connector. Use one Yellow butt connector supplied to splice the XTRE Black/Green wire (also labeled "to ECM") to the B/G wire end, which goes to the ECM connector.
- Page 3 2. Operation The unit is fully functional after installation. It will improve throttle response, acceleration and will also remove the speed limiter on 1000cc+ bikes. As such, using this product is not allowed on public roads. X-TRE will not disable the in-dash factory gear position indicator. The module automatically turns off the mapping in Neutral for smooth idle operation.
- Page 4 Our dealers are offering a 30-day money-back guarantee on HealTech products, thus you will get your money back if the product does not fulfill your expectations. (All parts must be returned in original condition for full refund.) Furthermore the product is covered by our 2-year replacement warranty from the date of purchase.
