QuickShifter easy
Supplementary Manual
Honda CB650F ABS 2014-2018 (iQSE-1 + QSH-P2T)
Secure the bike on a stand.
Remove the seat.
Remove the side fairings.
Locate the ignition coil connectors on the
right side under the side fairing.
