- Page 1 4×2 Matrix Switcher with USB Hub and HDBaseT Input Application Programming Interface Atlona Manuals AT-OME-MS42-HDBT Switchers...
- Page 2 Version Information Version Release Date Notes Jun 2024 Initial release AT-OME-MS42-HDBT...
- Page 3 Introduction General This document provides an alphabetical list of commands available for AT-OME-MS42-HDBT. Commands are case- sensitive. If the command fails or is entered incorrectly, then the feedback is “Command FAILED”. Commands can be sent using RS-232, Telnet, SSH, or TCP. There should be a 500 millisecond delay between each command sent to the unit.
- Page 4 Introduction RS-232 A 3-pin captive screw connector is included for RS-232, and should be wired as shown. Refer to the AT-OME-MS42- HDBT User Manual for details on RS-232 control. AT-OME-MS42-HDBT AT-OME-MS42-HDBT HDBT IN HDBT IN HDBT IN HDBT IN To display USB-C IN USB-C IN USB-C IN...
- Page 5 Commands Command Description Blink Enables or disables blinking of the POWER button on the front panel. DispBtn Simulates pressing the DISPLAY button on the front panel. help Displays a list of available help commands. InputStatus Displays the status for each input. IP802.1x Sets the security authentication type.
- Page 6 Commands Blink Enables or disables blinking of the POWER LED indicator on the front panel. When set to on, the POWER indicator will flash blue, and can be used to physically identify the unit on a network. The POWER indicator will flash until the Blink off command is executed or the unit is rebooted.
- Page 7 Commands help Displays the list of available commands. To obtain help on a specific command, enter the help command followed by the name of the command. Syntax help [X] Parameter Description Range Command name (optional) Command Example Feedback help Blink DispBtn System IPCFG...
- Page 8 Commands IP802.1x Sets the security setting for use with RADIUS server authentication. Use the sta argument to display the current setting. Syntax IP802.1x X Parameter Description Range Security setting disable, PEAP, TTLS, TLS, sta Example Feedback IP802.1x TTLS IP802.1x TTLS IPCFG Displays the current network settings for the unit.
- Page 9 Commands IPStatic Sets the static IP address, subnet mask, and gateway (router) address of the unit. Before using this command, DHCP must be disabled on the unit. Refer to the IPDHCP command for more information. Each argument must be entered in dot-decimal notation and separated by a space. The default static IP address is 192.168.1.254. Syntax IPStatic X Y Z Parameter...
- Page 10 Commands Mreset Resets the unit to factory-default settings. Syntax Mreset This command does not require any parameters Example Feedback Mreset Mreset OutHdmi5vKeep This option sets the +5V pin on the HDMI OUT port to the desired setting. This feature allows a display to go to sleep when there is no signal present.
- Page 11 Commands PWON Executing this command will power-on the unit. Use the PWOFF command to power-off the unit. Syntax PWON This command does not require any parameters Example Feedback PWON PWON PWSTA Displays the current power state of the unit. Syntax PWSTA This command does not require any parameters Example...
- Page 12 Commands RS232zone Sends commands to the HDBaseT device. Refer to the User Manual of the display device for a list of available commands. Brackets must be used when specifying the command argument. Note that this command has been deprecated and is for legacy use. It is recommended to use the TCP socket functionality, under Ports (page Syntax RS232zone[X]...
- Page 13 Commands Unlock Unlocks the buttons on the front panel. Also refer to the Lock command. Syntax Unlock This command does not require any parameters Example Feedback Unlock Unlock USBHostLogic Sets the USB mode for the AT-OME-MS42-HDBT. Use the sta argument to display the current setting. Syntax USBHostLogic X Parameter...
- Page 14 Commands UsbVbusControl This feature provides the ability to toggle the USB Vbus. This allows the USB hub port to always provide power or follow the presence of the connected USB host. Use the sta argument to display the current setting. Syntax UsbVbusControl X Parameter...
- Page 15 Commands Enables / disables video for the specified output. The first argument references the output: 1 = HDMI, 2 = HDBaseT. The second argument enables or disables the video output. on = enable video; off = disable video. Use the sta argument to display the current setting.
- Page 16 International atlona.com 408.962.0515 41.43.508.4321 • • 40315-R1...
