- Page 1 Installation instructions 5560 5580 28.05.2024 / 97-9716 www.hwam.com...
-
Page 3: Table Of Contents
Safety ..........................4 Room requirements ....................... 4 Technical measures and data - top- and back outlet HWAM 5560 ....4 Technical measures and data - top- and back outlet HWAM 5580 ....5 Type plate and serial number ..................6 Floor plate ........................ -
Page 4: Technical Data
To ensure optimum operation and safety, we recommend that the installation should be carried out by an authorised HWAM retailer or a fitter recommended by the retailer. For an overview of HWAM retailers, visit www. -
Page 5: Technical Measures And Data - Top- And Back Outlet Hwam 5580
Technical measures and data - top- and back outlet HWAM 5580 141,4 141,4 141,4 ,.,., ,.,., 141,4 .."" .."" "" "" ·- - - - - ·- - - - - 130; 130; SECTION A-A 407 5... -
Page 6: Type Plate And Serial Number
European, national and local regulations must be observed in terms of the size and thickness of a non-combustible floor covering the floor in front of the combustion chamber opening. Ask your HWAM retailer for assistance. The combustion chamber opening is 62.7 cm wide. -
Page 7: Requirements For Chimney And Flue Duct
T400 and be CE marked. Furthermore, it must have obtained the classification of G in soot fire testing. The required distance to combustible material must be complied with in accordance with the brand label. Ask your HWAM retailer for further information. -
Page 8: Illustrations Regarding Distance Requirement
Format: Fax (+45) 86 92 22 18 1:15 Scale: Created by: Item: 27-05-2019 Created date: 3891.81 Weight: Tolerance: Configuration name: UK - Hwam I40-55 sikkerh Material: Model: Sheet1 Status: Part: Format: 1:10 Scale: Thickness: Page 8 of 28 pages Weight:... - Page 9 Illustrations regarding distance requirement Combustible material Brændbart materiale Fire wall - min. 50 mm calcium silicate Brandmur - min. 50mm kalciumsilikat Mursten Status: Part: Page 9 of 28 pages Format: 1:10 Scale:...
- Page 10 Format: Fax (+45) 86 92 22 18 1:15 Scale: Created by: Item: 27-05-2019 Created date: 3891.81 Weight: Tolerance: Configuration name: UK - Hwam I40-55 sikkerh Material: Model: Sheet1 Status: Part: Format: 1:10 Scale: Thickness: Page 10 of 28 pages Weight: Material: 5500 - Loftshøjde...
-
Page 11: Installation Instructions
When handling the steel parts of the cladding parts it is advisable to wear clean cotton gloves to avoid leaving fingerprints. Connection of the HWAM SmartControl ®... - Page 12 Page 12 of 28 pages...
- Page 13 Page 13 of 28 pages...
- Page 14 Page 14 of 28 pages...
- Page 15 Page 15 of 28 pages...
- Page 16 Page 16 of 28 pages...
- Page 17 Page 17 of 28 pages...
-
Page 18: Procedure For Top Outlet Connection
Procedure for top outlet connection Page 18 of 28 pages... - Page 19 For installation of uninsulated flue gas pipe: For installation of insulated flue gas pipe: Page 19 of 28 pages...
-
Page 20: Procedure For Back Outlet Connection
Procedure for back outlet connection: Page 20 of 28 pages... - Page 21 Page 21 of 28 pages...
- Page 22 Page 22 of 28 pages...
- Page 23 Page 23 of 28 pages...
- Page 24 Page 24 of 28 pages...
- Page 25 23 13 Page 25 of 28 pages...
- Page 26 Page 26 of 28 pages...
-
Page 27: Product Information Ecodesign
• Dispose of the items correctly i.e. separate the parts to be disposed of in material groups • Always dispose of items in a way that is as sustainable as possible and that is in line with the current environmental protection, reprocessing/recycling and disposal technology HWAM A/S • Nydamsvej 53 • DK-8362 Hørning...
