- Page 1 User's Manual 3120 3130 01.11.2020 / 97-9658 www.hwam.com...
-
Page 3: Table Of Contents
Drawings ........... 4-7 HWAM SmartControl ®... - Page 4 Page 4 of 20 pages...
- Page 5 Page 5 of 20 pages...
- Page 6 Page 6 of 20 pages...
- Page 7 Page 7 of 20 pages...
- Page 8 Congratulations on your new wood-burning stove complete with a HWAM SmartCon- ® trol We are pleased that you have chosen a HWAM woodburning stove and confident that it will give you much pleasure. The HWAM SmartControl is a digital control of the combustion in your new wood-burning stove.
- Page 9 In general To ensure optimum operation and safety, we recommend that the installation should be carried out by an authorised HWAM retailer or a fitter recommended by the retailer. For an overview of HWAM retailers, visit www.hwam.com under “Retailer locations”.
- Page 10 The chimney and flue duct must be of flue class T400 and be CE marked. Furthermore, it must have obtained the classification of G in soot fire testing. The required distance to combustible material must be complied with in accordance with the brand label. Ask your HWAM retailer for further information.
- Page 11 An accessory top cover is available to cover the hole in the stove top plate if the smoke outlet is con- nected at the rear of the stove. Changing the smoke outlet from top outlet to back outlet, HWAM 3130 (drawing E) 1. Lift the cast-iron top (1) off the stove 2.
- Page 12 • Built-in pipe sleeve (12). Fits smoke flue. • Wall rosette (13). Covers disruption to wall around pipe sleeve. • Joint (14). Sealed with packing material. • Smoke outlets (15) of the HWAM stove. • Smoke flue regulating damper (16). • Soot door (17).
-
Page 13: Firing Manual - Wood
If the chimney is too tall to be cleaned from above, it must be equipped with a soot door. In case of a chimney fire and overheating, the HWAM SmartControl will enter a security mode and ®... - Page 14 In certain cases it is necessary to assist the draught in the chimney by opening the door to the burning chamber 3-5 minutes before lightning the stove. Read more on www.hwam.com about the function of the chimney.
-
Page 15: Firing In General
• If the room temperature after a new restoking still does not reach the desired level, the water content in the firewood may be too high or the draught in the chimney too weak. The HWAM ® SmartControl always strives for a sufficiently high flue gas temperature to ensure an environmen- tally friendly combustion. -
Page 16: Maintenance
A good combustion is achieved when the fire gets the right amount of oxygen supply at the right time and place in the combustion chamber. The HWAM SmartControl allows for varia- ®... - Page 17 • Lift each half of the steel smoke plate (4) off the holder (5) behind the smoke pipe, and remove them from the hook (6) beneath the top plate. Ashes The ash pan is best emptied by pulling a waste bag over the pan, tipping it and then carefully pulling it out of the bag.
-
Page 18: Operational Problems
In case the safety alarms go off, you must not use the stove. Contact your retailer as soon as possible. At interruptions that you cannot yourself rectify, you should contact the retailer. eClArAtIon oF erForMAnCe The DoP can be downloaded from our website via the following link: www.hwam.com/dop/3120ihs www.hwam.com/dop/3130ihs Page 18 of 20 pages... - Page 19 • Always dispose of items in a way that is as sustainable as possible and that is in line with the current environmental protection, reprocessing/recycling and disposal technology HWAM A/S • Nydamsvej 53 • DK-8362 Hørning Page 19 of 20 pages...
