TX-6000/6000E/6100/6100E
Fanless POS Box
User Manual
TX-6000/6100
Package Contents
TX-6000/6000E/6100/6100E POS box........................(x1)
12VDC/60W power adaptor (TX-6000/6100)
or 12VDC/150W power adaptor (TX-6000E/6100E).......(x1)
Power cord.........................................................(x1)
Wall-mount bracket (optional).................................(x1)
TX-6000/6000E/6100/6100E Ver. B0
TX-6000E/6100E
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for POSIFLEX TX-6000
Summary of Contents for POSIFLEX TX-6000
- Page 1 TX-6000/6000E/6100/6100E Fanless POS Box User Manual TX-6000/6100 TX-6000E/6100E Package Contents TX-6000/6000E/6100/6100E POS box…………...……...(x1) 12VDC/60W power adaptor (TX-6000/6100) or 12VDC/150W power adaptor (TX-6000E/6100E)...….(x1) Power cord………………………………………….…..(x1) Wall-mount bracket (optional)……………………….…..(x1) TX-6000/6000E/6100/6100E Ver. B0...
- Page 2 SOME IMPORTANT NOTES FCC NOTES This system meets industry & government requirements and applicable standards. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class A digital device pursuant to subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against interference when operated in a commercial environment.
- Page 3 SAFETY INSTRUCTIONS This equipment is not suitable for use in locations where children are likely to be present. CONSIGNES DE SÉ CURITÉ Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des enfants. WARNING Power cord shall be connected to a socket-outlet with earthing connection. ATTENTION Le cordon d'alimentation doit être connecté...
- Page 4 Views Front View of TX-6000/6100 Power Status LED Indicator Line-out/Mic-in Combo Power Button USB 2.0 Port Storage Status LED Indicator Front View of TX-6000E/6100E Line-out/Mic-in Combo Power Button Power Status LED Indicator Powered USB Port Storage Status LED Indicator Top View of TX-6000/6000E/6100/6100E...
-
Page 5: Rear I/O Ports
Bottom View of TX-6000/6000E/6100/6100E Rubber Pad Rubber Pad Service Door Rear I/O Ports TX-6000/6000E Type-C port USB 3.0 ports RJ45 LAN port USB 2.0 ports Cash drawer (CR) port HDMI port HDMI port VGA port Serial COM (DB9) ports Serial COM (RJ50) ports... - Page 6 TX-6100/6100E Type-C port USB 3.0 ports RJ45 LAN port USB 2.0 ports Cash drawer (CR) port HDMI port HDMI port VGA port Serial COM (DB9) ports Serial COM (RJ50) ports 12V Powered USB port 12VDC-IN power jack Connecting Power Adapter and I/O Cables To have the terminal ready for operation, please connect the connector of power adapter and all of the connectors of required I/O cables respectively to the 12VDC-IN power jack and appropriate I/O ports.
-
Page 7: Installing A Memory Upgrade Module
Le cordon d'alimentation doit être connecté à une prise de courant avec mise à la terre. Note: The COM ports of TX-6000/6000E/6100/6100E do not supply power by default. To make the COM ports supply power, you can set up the COM ports through the dedicated settings listed in the table below. - Page 8 To avoid users from damaging the main board of the system, it is highly recommended that the memory expansion and replacement are implemented by professional technicians. Mounting the TX-6000(E)/6100(E) on the Wall (Optional) 1. Fix the wall mount bracket onto the wall by using attached plastic anchors and four M3.5- 16L screws.
-
Page 9: Specifications
Status LED Indicator There are two status LED indicators, power status LED indicator and SSD status LED indicator, on the front side of the TX-6000/6000E/6100/6100E. After powering ON the POS system, you can read the system operation status from the power and SSD status LED indicators. The LED status is described below. - Page 10 TX-6000E/6100E: 12VDC power adaptor, 150W CR Port CR port x 1, controlling 2 cash drawers TX-6000/6100: USB 3.0 x 4 + USB 2.0 x 5 Standard USB Port TX-6000E/6100E: USB 3.0 x 4 + USB 2.0 x 3 TX-6000/6100: N/A...
-
Page 11: Outline Dimension
Outline Dimension ※ The product information and specifications are subject to change without prior notice.
