TX-1000A/1000AE
Fanless POS Box
User Manual
Package Contents
POS box.........................................................................(x 1)
Power adaptor..................................................................(x 1)
Power cord......................................................................(x 1)
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement
résidentiel, cet équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than
the authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise.
The manufacturer is by no means responsible for any damage or hazard caused by improper
application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne
autre que les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le
problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions
d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout
dommage ou danger causé par une mauvaise application.
TX-1000A/AE Ver. A0
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TX-1000A and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX TX-1000A

  • Page 1 L'utilisateur doit consulter son revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise application. TX-1000A/AE Ver. A0...
  • Page 2 警告 為避免電磁干擾,本產品不應安裝或使用於住宅環境。 SAFETY INSTRUCTIONS This equipment is not suitable for use in locations where children are likely to be present. CONSIGNES DE SÉ CURITÉ Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des enfants. WARNING Power cord shall be connected to a socket-outlet with earthing connection ATTENTION Le cordon d'alimentation doit être connecté...
  • Page 3 Views of the TX-1000A/1000AE Front View of TX-1000A Power Status LED Indicator Micro SD Card Slot Power Button Micro USB Port Front View of TX-1000AE Power Status LED Indicator Micro SD Card Slot Power Button Micro USB Port 24V PoweredUSB...
  • Page 4 View of Rear I/O Interface of TX-1000A/1000AE Mic-in & Line-out Combo COM ports (RJ50) 12V poweredUSB (Only for COM ports (DB9) TX-1000AE) USB 3.0 port USB 2.0 ports LAN port (RJ45) HDMI ports CR port 12 VDC-IN power jack Connecting Power Adapter and I/O Cables Please follow the steps described below to connect power adapter and I/O cables.
  • Page 5 Paring Information for HDMI Port & USB Port There are two HDMI ports for TX-1000A/1000AE. Please refer to the below table to connect the 1st monitor (main monitor) and the 2nd monitor. Monitor Monitor (Main Monitor) Display Touch Display Touch...
  • Page 6 Powering ON/OFF TX-1000A/1000AE Power ON TX-1000A/1000AE Press down the power button and hold down the power button for at least 3 seconds to power on TX-1000A/1000AE. Power OFF TX-1000A/1000AE In most cases, push the power button again to power off the system.
  • Page 7: Operation Environment

    Operation Environment To prevent TX-1000A/1000AE from overheating, it is suggested to position your terminal in a well-ventilated working environment. In doing so, please be advised to keep the POS box at least 25mm away from other devices to ensure the machine is properly cooled down and functioning normally.
  • Page 8: Outline Dimension

    Outline Dimension ※ The product information and specifications are subject to change without prior notice. To get the detailed information on TX-1000A/1000AE, please check this model from Posiflex Global Website (http://download.posiflex.com/en- global/Download/download).
