Zaxcom RX200

Setting the Scan Range

SCAN LIMIT:
ALL 200 512 - 698
The scan range menu sets the frequency range that the RX200 will scan when doing a frequency scan. Pressing
the INC and DEC key will cycle through the scanning options. If the scan range is changed the RX200 will
automatically jump back to the scanning menu when the MENU key is pressed.
Available Scan Ranges
All 200 - All frequencies from 512.0MHz through 698.0MHz will be scanned..
•
LO 100 - Corresponds to the frequency range of 3.5 transmitters, when selected the RX200 will scan all
•
frequencies from 512.0MHz through 614.0MHz.
HI 100 - Corresponds to the frequency range of 3.6 transmitters, when selected the RX200 will scan all
•
frequencies from 596.0 through 698.0MHz.
BLK (20 -26) - Allows the RX200 to scan a specific block (Blocks 20-26).
•
Block 20 - 518-542 MHz
•
Block 21 - 536-572 MHz
•
Block 22 - 560-590 MHz
•
Block 23 - 590-614MHz (block 23 needs to be enabled)
•
Block 24 - 614-644 MHz
•
Block 25 - 638-668 MHz
•
Block 26 - 662-698 MHz
•

Test Tone Output

TONE :
OFF
The test tone menu allows the RX200 to output tone from the TA5 outputs. This is useful to set levels and
check routing. Pressing the INC and DEC key will cycle through the different tone settings.
OFF - No tone is being outputted.
•
-20dBFS -Tone is simultaneously sent to both outputs at -20dBFS.
•
+0dBFS - Tone is simultaneously sent to both outputs at full scale 0dBFS.
•

Time Code

TC: 02:09:18:05
The time code menu displays the time code that the RX200 is receiving from the transmitter. The RX200
will automatically detect and adjust and display the time code frame rate.
29.97DF
9
Main Menu
