1. OLED Display
2. INC Key - Used to increase the parameters of a menu item.
3. UHF Antenna Connectors (2) – SMA connectors.
4. Receiver Sataus Indicator
Red - RX200 is not getting a valid signal
Green - RX200 is getting a valid signal
5. DEC Key - Used to decrease the parameters of a menu item.
6. Menu Key - Used to advance to the next menu item.
7. Power Switch
