Blue LED Set

LED METER MODE:
BLUE PLUS METERS
The LED meter mode sets the action of the side mounted LEDs. The side mount LEDs were designed to give
visual confirmation that audio and RF is being received at the RX200.
BLUE ONLY - The middle LED will illuminate blue when the RX200 is receiving a valid RF signal and the other
•
LEDs will not illuminate.
BLUE PLUS METERS - In mono mode the bottom LED will illuminate blue when a valid RF signal is being
•
received. Then when audio is being received the LED's will illuminate according to the level of the signal.
In stereo mode the middle LED will illuminate blue when a valid RF signal is being received. Then the LED
above will illuminate when audio is being received on the left channel and the bottom LED will illuminate
when audio is being received by the right channel.
Mono mode LED colors

LED Brightness Set

LED DIMMER:
OFF
The LED brightness menu sets the brightness of the side mount LED's.
Off - The LEDs will not illuminate.
•
Numeric Value - (variable values) - Adjustable brightness levels.
•
Bright - The LEDs are on their brightest setting.
•

OLED Brightness

OLED BRIGHTNESS:
3
The OLED brightness menu adjusts the brightness of the OLED display. The brightness can be adjusted from 0 to
3 with 0 being the dimmest setting and 3 being the brightest.

Hide Encryption Menu

ENCRYPTION MENU:
HIDDEN
This menu allows for the encryption menu to be hidden preventing accidental changes.
HIDDEN - The encryption menu does not appear when cycling through the menu settings.
•
SHOW - The encryption menu will appear.
•
Stereo mode LED colors
When the signal is -20dBFS or less
When the signal is between -19 and -6 dBFS
When the signal is -5dBFs and above
