Setting the Scan Range

SCAN LIMIT:
ALL 200 512 - 698
The scan range menu sets the frequency range that the URX100 will scan when doing a frequency scan. Pressing
the CH UP and CH DOWN keys will cycle through the scanning options.
Available Scan Ranges
All 200 - All frequencies from 512.0MHz through 698.0MHz will be scanned..
•
LO 100 - Corresponds to the frequency range of 3.5 transmitters, when selected the RX200 will scan all
•
frequencies from 512.0MHz through 614.0MHz.
HI 100 - Corresponds to the frequency range of 3.6 transmitters, when selected the RX200 will scan all
•
frequencies from 596.0 through 698.0MHz.
BLK (20 -26) - Allows the RX200 to scan a specific block (Blocks 20-26).
•
Block 20 - 518-542 MHz
•
Block 21 - 536-572 MHz
•
Block 22 - 560-590 MHz
•
Block 23 - 590-614MHz (block 23 needs to be enabled)
•
Block 24 - 614-644 MHz
•
Block 25 - 638-668 MHz
•
Block 26 - 662-698 MHz
•
