Audio Output Connector TA5

Single Analog Channel out - TA5

Two Analog Channels out - TA5

AES Digital out of TA5

The TA5 connector is also used to output AES digital audio. TheTA5 will output a stereo pair on pins 1, 2 and 3
with pin 1 being ground.
When receiving audio from a mono transmitter the RX200 will output the same audio on both pairs on the TA5.
IMPORTANT: While sending digital audio, it is necessary that the unit on the other end (recorder, mixer, etc.)
have digital inputs with a sample rate convertors, as there is no other way to synchronize the output data with
the recorder's digital input.

12 Volt DC power - Switchcraft 760K

TA5 out on
RX200
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
TA5 Out on
RX200
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
TA5 out on
RX200
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
DC Power
In
+
-
XLR into Camera or
Mixer
PIN 1
PIN 2
PIN 3
No Connection
No Connection
XLR into Camera or
Mixer
PIN 1 XLRs
on both
PIN 2 - Left
PIN 3 - Left
PIN 2 - Right
PIN 3 - Right
XLR into Camera or
Mixer
PIN 1
PIN 2
PIN 3
No Connection
No Connection
CENTER PIN
SLEEVE
