Zaxcom QRX200

Wiring Diagrams

Audio Output Connectors

There are two TA-5M connectors on the back panel. How they are used varies based on the output configuration
in the extended menu.

Single Analog Channel out of one TA5

Two Analog Channels out of one TA5

AES Digital out of TA5

The TA-5 connectors can also be used to output AES digital audio. Each TA5 will output a stereo pair on pins
1, 2 and 3 with pin 1 being ground.
When receiving audio from a mono transmitter the QRX will output the same audio on both pairs of the
TA5. When receiving audio from a stereo transmitter the QRX can output both signals on a single TA5.
IMPORTANT: While sending digital audio, it is necessary that the unit on the other end (recorder, mixer, etc.)
have digital inputs with sample rate convertors, as there is no way to synchronize the output data with the
recorder's digital input.
TA5 out on
QRX
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
TA5 Out on
QRX
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
TA5 out on
QRX
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
XLR into Camera or
Mixer
PIN 1
PIN 2
PIN 3
No Connection
No Connection
XLR into Camera or
Mixer
PIN 1 XLRs
on both
PIN 2 - Left
PIN 3 - Left
PIN 2 - Right
PIN 3 - Right
XLR into Camera or
Mixer
PIN 1
PIN 2
PIN 3
No Connection
No Connection
18
