Mounting & Installation
1) The RF1B receiver should be wall mounted in an area within
20 metres distance of the wireless thermostat. It is important
that the receiver has over 25cm clearance from metal objects as this
will a ect communication with the thermostat.
The receiver should be installed at least 1 metre from any electronic
devices such as radio, TV, microwave or wireless network adapter.
2) Use a Phillips screw driver to loosen the screws of the backplate
on the bottom of the RF1B. The receiver is lifted upwards from the
bottom and removed from the backplate. (see page 17)
3) Screw the backplate to the wall with the screws provided.
4) Wire the backplate as per the wiring diagram on page 14.
5) Mount the receiver on the backplate making sure the pins
and the backplate contacts are making a sound connection. Push
the receiver ush to the surface and tighten the screws of the
backplate from the bottom. (See page 17)
6) If installing more than one RF1B receiver ensure they are 25cm
apart.
16
RF1B Wireless Receiver CP4
V2
