Button / LED Description
Hub LED
System LED
Manual override
button
Manual override
Manual
Reset button
Press to reset the
receiver
Note:
Please refer to Page 14 for wiring information.
Reset button
Connect:
Connect
Once voltage has been applied this button
may be held to initialise the pairing process
with the wireless thermostat. Once
pressed the RF LED will begin to ash.
RF1B Wireless Receiver
RF LED
OpenTherm LED
Connect button
CP4
V2
57
