INSTALLATION INSTRUCTION
DETAILED PARTS AND ASSEMBLY PROCEDURE
Note :
Check direction when installing
sleeve ring to the tube.
Note : All parts above are Metric thread.
Single Point Remote Installation Kit for Pulsarlube OL
LIST
PART No.
OL500
Pulsarlube OL
A002
Reducer, 3/8"F X 1/8"M Adaptor
B002
Mounting Bracket, "L"Shape
B057
Washer
B051
Self Drilling Screw, #8 X 19
A012
Socket, 1/8"F x 1/8"F Adaptor
C007
Tube Fitting, Dia. 4mm x PT1/8"M
C010
Tube Clamp, Dia. 4mm x 1R
Distribution Tubing, O.D. 4mm x I.D. 2.5mm
C021-1
Nylon Tubing, 10ft (3m)
C011
Insert, Dia. 4mm x 2.5mm
C009
Sleeve Ring, Dia. 4mm
NOTE : Oil brush and bracket assembly is available (sold separately).
ASSEMBLY PROCEDURE
1. Install the mounting bracket (
for easy installation and filling of oil.
2. Install the lubricator using the reducer (
3. Remove the oil reservoir lid and fill the cartridge with oil to the 500ml level on the
label. Turn the hand knob counter clockwise 1~2 turns before closing the lid to
open the vent and relieve vacuum pressure.
4. Press the "TEST" button for 2 seconds to run test mode.
Confirm that the unit is dispensing oil properly.
5. Assemble the socket (
) and the fitting connector (
6. Connect each end of the tubing to the fitting connector (
(
) and sleeve ring (
(If an oil brush and bracket assembly are to be used, connect brush to a fitting
connector (
) at the end of lube line using an appropriate socket.)
7. Use the tube clamps (
) and screws (
8. Install lubricator and follow lubricator operation insturctions on user manual.
COMMENTS
1. Apply PTFE tape on all assembly points to prevent leakage.
2. Please check for compatibility between oil being used and plastic that lubricator
is made of.
- Synthetic Hydrocarbons, PAO : Compatible
- Silicones (All Types) : Compatible
- Fluorinated Esters : Compatible
- Esters & Polyglycols : May cause a problem
3. Output volume may vary depending on oil viscosity, length of lube line, ambient
temperature, etc.
Rev.01
DESCRIPTION
) at a proper location using screws (
), washer (
) in order, as shown in the circled image on the left.
) to affix the tubing (
Kit No. 1250RO-1
Q'TY
N/A
1
1
1
5
1
2
2
1
2
2
) to allow
), and socket (
).
).
). Assemble the insert
) to a wall.
www.pulsarlube.com
