The Pulsarlube ML 500cc
Electro-Mechanical Unit
Specifications:
* Operating temperature for Standard Battery: 14° F ~ 122° F (-10° C~50° C)
Lithium Battery: -40°F~140°F (-40°C~+60°C)
* Normal operating pressure: 280psi (20kgf/cm²)
* Grease Capacity: 500cc
* 5 Standard greases available (OEM grease filling available)
* Variable Settings Available: ½, 1, 2, 4, 6, 12, 18, 24 months
* Default Setting: 1 Month
* D.C. 4.5-Volt Lithium Battery
* Service Pack Replacement
* LCD locking system included
* Can be used to lubricate multiple points (Up to 8 points).
Dimensions: 500cc
Packaging: Each 500cc unit is individually packaged. (8 units per case; 23.00Lb/case)
Replacement part #'s;
* B001:
Standard Battery Pack
Three 1.5V Duracell Alkaline Batteries create one DC 4.5V Standard Battery Pack
* LTB001: Lithium Battery (For low Temps, High Back Pressure & or 24 month settings)
Three 1.5V Energizer Lithium Batteries create one DC 4.5V Standard Lithium Battery Pack.
* P500:
Disposable 500cc Grease pouch.
* D500:
500cc Dust Cover (Transparent Plastic cover)
* H500:
500cc Top Housing (Transparent Plastic Housing)
Pulsarlube USA, Inc
4312 DiPaolo Center. Glenview, IL 60025
TEL: 847-795-0591
FAX: 847-7895-0119
Web Site:
www.pulsarlubeusa.com
Email: info@pulsarlubeusa.com
Diameter: 3.6 inches, Height: 9.5 inches, Weight: 2.65Lb(1.20Kg)
Pulsarlube USA, Inc.
ISO9001 Registered, Single Point Lubricator Company
Product Number: ML500
General Description:
The ML500 consists of a vertical feed pump,
motor/gear
set,
system, which delivers an outstanding operating
pressure available of (280 psi, 20Kg-f/cm²) The
lubricant is supplied in 500cc Pulsarlube grease
pouches, which are replaceable along with a
Pulsarlube battery pack. It offers 8 optional
dispensing rates from ½ (Half) to 24 months in a
single unit.
FORM
DOC#: PM-T-101
Aug, 2007(Rev05)
and
Microprocessor
control
