1. General Information
1-1. Product Description
Technical information is subject to change without notice.
Speci cations
Oil Reservoir Capacity
Operation Pressure
Power Supply
Output Current
Operation Temperature
RESET
PURGE
LOCK
POWER
MODE
Available Dispensing Periods
LCD
• To ensure the safe operation and proper installation of the Pulsarlube PLC-OL480 unit, we strongly recommend that
you read the following information carefully before use.
• If you require further information, please contact your local supplier or manufacturer.
1-2. LCD Display Description
480 480
Backlit LCD Extreme Blinks when
Backpressure selected cycle
Indication ends
1-3. PLC Connecting Cables (colors) (Body Cable View)
RESET
PURGE
LOCK
POWER MODE
NOTE
'+' Black
'-' Blue
PNP TYPE
Description
480ml (Re llable)
10bar (145psi) (Depends on oil viscosity)
DC 9 ~ 36V
Max. 1A (1,000mA)
-20℃ ~ 60℃
MONTH TYPE : 1 ~ 12 Month
INTERVAL TYPE : 1 ~ 6 Mode
Backlit LCD
Dispensing period
Automatic
Lock Out mode
480
Operating Status
Purge mode
Purging Status
in operation
①
Black VCC (Power Supply Cable)
②
White Signal Out (Alarm Signal Cable)
③
Blue GND (Power Supply Cable)
④
Brown Signal In (Operation Signal Cable)
1-3. Connection Methods (Extension Cable)
PNP TYPE (SOURCE)
PULSARLUBE PLC
1-4. Accessories for Oil Lubrication
Remote / Multi Point Installation Kits (Kit No.1250RO1~4) and Brush kits (Kit No.C030~33,
C036~39) are sold separately. Please refer to the Accessories page and Kit user manual on
the website.
2. Installation and Operation
2-1. Installation Guidelines
RESET
PURGE LOCK
POWER MODE
Direct Mount,
Brush Kit
Remote
480
Installation Installation
Single Point Installation using Brush Kit
Install appropriate accessories and brush kits.
Multi Point Installation using
Multi Point Installation Kit
Install appropriate
accessories and brush kits.
• Mount the Pulsarlube PLC-OL480 unit in close
proximity to the application to keep feed lines as
short as possible.
• Accessories are sold separately.
POWER SUPPLY
in
+ + + +
POWER
out
SUPPLY
(24V)
24V
- - - -
0V
RESET
PURGE LOCK
POWER MODE
TIP. Fill the oil using the lter.
After install the appropriate accessories for the selected
installation method, remove the oil reservoir lid and ll the
reservoir with oil to the 480ml level.
Turn the hand knob counter clockwise 1~2 turns before
closing the lid to open the vent and relieve vacuum
pressure.
PLC CONTROLLER
Q0
0
Q1
0 I0 1
1 I1 2 Q2
2 I2 3 Q3
3 4
I3 Q4
4 5 Q5
I4
5 I5 6 Q6
6 7 Q7
I6
7 I7 V+
COMO V+
COMO V-
Digital I/O (Input/Output)
