Pulsarlube MS60 User Manual

O
perating Principles
The Pulsarlube MS unit turns "On" or "Off" in synchronization with the equipment on which it is installed. It will
dispense the preset amount of grease as long as the machine is operating. If the equipment is not operating,
then the Pulsarlube MS unit goes into "stand-by mode" and does not dispense lubrication until the machine
operates again.
The MS unit is not an externally powered unit. It operates on its own battery.
Battery should be replaced simultaneously with grease pouch. The MS unit will turn ON/OFF
through a Relay Box in accordance with the related equipment power signal.
M
ain Unit specification
Item
Models Available
Operating Pressure
Operating Temp Range
Multi Point Lubrication
Power Source
Other Functions
Product upgrades may occur without prior notice for quality purposes.
R
elay Box Specifications
Item
Voltage Rate Input
Voltage Rate Output
Power ON Indicator
Relay Box Dimensions (mm)
Input
Power
Supply
Wire
Output
Side
Length
Main Unit Side
Note: The MS Relay Box was designed for the Pulsarlube MS unit only.
Product warranty will be null &void if any other type of unspecified adapter or converter is used.
O
perating the Pulsarlube MS
The MS functioning process
2) Working for 10 days
1) Month setting
250
Power on
Description
60ml, 125ml, 250ml
30Kgf/
-15˚C~60˚C (5˚F~140˚F)
Up to 8 points
DC 4.5V Replaceable Alkaline Battery
Same as the Pulsarlube M lubricator
Description
AC 100~480V, 0.5W
50 ~ 60Hz
Signal (Open collector Type)
Red LED
85(D) x 49(W) x 32(H)
1M
4.5M
90mm
250
3) Off for 10 days
10 20
Pulsarlube MS (Machine Synchronized Lubricator)
(425psi)
4) Working again for 20 days
250 250 250 250
30
Doc No. 1082-000 REV. 140203
250
LCD RED LED Signal
lamp blinking
5) Finished
40
Total days
