Pulsarlube 1250RO-2 Installation Instruction

INSTALLATION INSTRUCTION
DETAILED PARTS AND ASSEMBLY PROCEDURE
No. Part No.
OL unit Pulsarlube OL
A002 Reducer, 3/8"F X 1/8"M Adaptor
B002 Mounting Bracket, "L"Shape
B057 Washer
B051 Self Drilling Screw, #8 X 19
C006 Reducer, PT 1/8"F X M8 X 1P
C003-1 Distributor, 3(1P) M8 x 1P
C003-2 Distributor, 4(2P) M8 x 1P
C003-3 Distributor, 5(3P) M8 x 1P
Resistance Valve, #1 Distributor Spray
C004-1
(one-touch type)
Distribution Tubing, O.D. 4mm x I.D. 2.5mm
C021-2
Nylon Tubing, 20ft (6m)
Distribution Tubing, O.D. 4mm x I.D. 2.5mm
C021-3
Nylon Tubing, 30ft (9m)
Distribution Tubing, O.D. 4mm x I.D. 2.5mm
C021-4
Nylon Tubing, 40ft (12m)
C010 Tube Clamp, Dia. 4mm x 1R
C007 Tube Fitting, Dia. 4mm x PT1/8"M
C011 Insert, Dia. 4mm x 2.5mm
C009 Sleeve Ring, Dia. 4mm
Cable Tie
A002
B002
Description
NOTE : Oil brush and bracket assembly is sold separately (sold separately).
B057
B051
C004-1
Multi-Point Remote Installation Kit for Pulsarlube OL
Available Kits & Component Parts
1250RO-2
7ea
1ea
-
-
2ea
1ea
-
-
4ea
2ea
2ea
2ea
4ea
C006 C003-1
C021-2 C021-3 C021-4
Cable Tie
Rev.03
Kit No. 1250RO-2, 1250RO-3, 1250RO-4
1250RO-3
Sold Separately
1ea
1ea
1ea
9ea
1ea
-
1ea
-
3ea
-
1ea
-
6ea
3ea
3ea
3ea
6ea
C003-2
C010 C007
1250RO-4
11ea
-
-
1ea
4ea
-
-
1ea
8ea
4ea
4ea
4ea
8ea
C003-3
C011 C009
www.pulsarlube.com
