Pulsarlube EX125 User Manual

Product Details
Housing
LCD
Main
Body
Connecting Thread
(3/8" M BSPT)
Installation/Disposal Guidelines
1 3
Pouch
Spring
Pouch
Plate
Check the grease pouch capacity and the
Remove contaminants around
service pack items (battery pack, grease
the lube point.
pouch & dust cover).
Grease 2 4
Pouch
Pump
Ensure a clear passage using a manual Insert a new battery pack.
grease gun.
Note1 Remove any hardened grease
by purging the lube point with a manual grease gun.
The grease in the equipment and the grease
Note2
contained in the unit should be the same or compatible.
5
Worm
Note
Gear
Remove the grease nipple and install Purge the grease pouch until grease comes
appropriate adaptors. out of the tip.
6 9
Carefully screw the grease pouch in by Select the appropriate grease pouch
turning clockwise. Do not over tighten. capacity by pressing the 125/250/TEST
button.
7 10
Refit the top housing on the unit and turn Press the MODE button to program the
clockwise until it clicks. dispensing period.
8 11
Press the POWER button for 2 seconds to Press the TEST button for 2 seconds
turn the unit on to run a test cycle and check for proper
operation of the unit.
Troubleshooting Guidelines
12
Symptom: Blank LCD screen
Possible Cause: Electrical malfunction of CPU
or circuitry, battery problem
Solution: Replace battery pack or press reset
button to restart the lubricator. If the problem
Note the installation date and the scheduled
persists, contact your supplier.
completion date of lube cycle on the lubricator
using the label provided in the Service Pack for
maintenance purposes.
13
Symptom: Low Battery Indication
Possible Cause: Rapid power consumption due
to improper storage or harsh operating conditions
(temperature, humidity, or high backpressure).
Remedy: Store the battery pack in cool, dry place
and choose proper battery type for application.
Install the Pulsarlube EX unit on the lube point.
Optional lithium battery pack is available for more
When the selected dispensing period has
advanced applications.
completed, replace the unit with the Service
Pack according to step #3~7.
14
Symptom: Excessive Backpressure Indication
Possible Cause: Excessive backpressure due to
hardened grease, over-lubrication, ruptured lube
line, long distance remote installation, etc.
Solution: A) Check backpressure at lube point
Install the dust cover over the lubricator for
and/or lube line, B) check grease dispensing rate,
added protection.
C) reduce remote installation distance, or D) use
manual grease gun to clear blockage.
