Pulsarlube V series User Manual

Product Details
Mode Cap
LCD
Mode
Button
Battery PCB
Screw Cap
Piston
Lubricant
Reservoir
Cylinder
Connecting Thread
(3/8" M BSPT)
Protector
Installation/Disposal Guidelines
1 3
Remove the protector.
Remove contaminants around
the lube point.
2 4
Ensure a clear passage using a manual Turn the mode cap counterclockwise
grease gun. and unscrew the cap.
Remove any hardened grease
Note1
by purging the lube point with a manual grease gun.
The grease in the equipment and the grease
Note2
contained in the unit should be the same or compatible.
5
Note
Remove the grease nipple and install Press the MODE button firmly to activate the
appropriate adaptors. unit.
6 7
Select the dispensing period by pressing Once the dispensing period is set, screw
the MODE button. the mode cap back on.
LCD Display
8
Each single press of the button
advances to the next setting as follows.
Log the installation date and the scheduled
date of lube cycle completion on the label
of the Pulsarlube V.
Purge Mode
9
Purge mode dispenses a large quantity of
grease in less than an hour. After the Purge
mode is used, reset the unit to the desired
dispensing period for further use.
Install the Pulsarlube V unit on the lube
point.
Mounting Installations
High backpressure can cause a
10
delay in dispensing (must be under 5
bar).
When the selected dispensing period of
the Pulsarlube V has completed, remove
the lubricator from the application.
If the product is installed at a 45°
or 90° angle, please use an angle
This product is a
adapter with a diameter greater than
11
disposible unit. Dispose
or equal to 1/4".
of remaining plastic
components complying
with local regulations for
recycling.
Warning
Do not cut, puncture, or reuse
lubricator. Do not change or
recharge the battery.
For remote installation using an 8mm
12
O.D. tubing, keep the maximum
distance at 1m (3ft) or less.
To avoid any potential injury or hazard, do
not tamper with the product.
