Thank you for buying a SAUTER force gauge. We hope
you are pleased with your high quality force gauge with its
big functional range. If you have any queries, wishes or
helpful suggestions, do not hesitate to call our service
number.
„Sensor Outside" means the cell is outside the body.
1.
Included in Delivery
-
SAUTER FH, incl. rechargeable battery
-
Carrying Case
-
Charger
-
Standard Attachments, 5 pcs. M3x 8 screws
Pilot lamp
Force sensor
RS 232 port
FH_SO-BA-e-1112
Sauter GmbH
Tieringerstr. 11-15
D-72336 Balingen
E-Mail: info@sauter.eu
Instruction Manual
FH
Important annotation:
By pressing the RESET key (on the right side of housing,
see illustration on the left), individual settings and
memorised values can be re-set or erased, in example for
a new start of the instrument after an operating error.
Data in mm
Set
LCD
Length of cable between display and sensor: 2500 mm
Terms:
Track
Peak
Tel: +49-[0]7433- 9976-174
Fax: +49-[0]7433-9976-285
Internet: www. sauter.eu
Sensor
Outside
FH 1k
– 20k
FH 50k
L
FH 100k
= continuous measurement
= Capture of the maximum value
B
1
