" Risk to health due to noise. The permissible noise
level is exceeded during operations. It is essential
that personal protective equipment, such as hearing
protection, is worn.
" Hazard due to electrical power, with the use of im-
proper electrical connection cables.
" Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
" Residual risks can be minimised if the <safety in-
structions= and the <Proper use= are observed along
with the whole of the operating instructions.
Ensure careful storage of the safety instructions.

6. Technical data

Suction port, connection Ø
Hose length
Air power
Pressure diference
Filter surface
Container volume
Weight
Electric motor
Rated input
Motor speed
Technical changes reserved!
Noise and vibration
m Warning: Noise can have serious efects on your
health. If the machine noise exceeds 85 dB (A), please
wear suitable hearing protection.

Unpacking

7.
m ATTENTION!
The device and the packaging material are not
children8s toys! Do not let children play with plas-
tic bags, olms or small parts! There is a danger of
choking or sufocating!
" Open the packaging and carefully remove the de-
vice.
" Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
" Check whether the scope of delivery is complete.
" Check the device and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
" If possible, keep the packaging until the expiry of the
warranty period.
" Familiarise yourself with the product by means of the
operating instructions before using for the orst time.
" With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
" When ordering please provide our article number as
well as type and year of manufacture for your equip-
ment.
100 mm

8. Assembly / Before commissioning

2000 mm
215 m³/h
m ATTENTION!
Always make sure the device is fully assembled
25000 Pa
before commissioning!
0.3 m²
8.1 Installing the olter cartridge (10) with olter bag
65 l
(11), Fig. 3 - 5
5 kg
" Insert the olter cartridge (10) into the olter bag (11).
220 - 240 V~
(Fig. 3 + 4)
50/60 Hz
" Press the overhang into the olter cartridge (10). (Fig.
1200 W
4)
" Now ot the olter cartridge (10) on the engine housing
35000 min -1
(1). (Fig. 5)
" Place the complete engine housing (1) on the con-
tainer (3) and lock the locking hooks (9).
8.2 Installing the suction hose (5), Fig. 6 + 7
" Fit the suction hose (5) with the hose clamp (8) on
the hose port of the container (3).
" Fit the other side of the suction hose (5) with the
hose clamp (8) and hose coupling (7).
9.

Start up

m ATTENTION!
Always make sure the device is fully assembled
before commissioning!
9.1 Switching on/of, Fig. 1
" To switch on, set the ON/OFF switch (4) to position <I=.
" To switch the device of again, set the ON/OFF
switch (4) to position <0=.
