PPC RFID_98R3P300010
Startup Manual
Ordering Information
P/N
Description
98R3P300010
PPC-300 RFID Read only 13.56MHz
& 125k
Specifications
General
• Interface: USB
• Cable Length: 50cm
• Frequency: 13.56 MHz & 125KHz
• RFID Read Mode: Supports ISO14443A/B, 125KHz,
(MifareS50/S70, Ultralight, FM1208, Desfire, EM4100,
T5577)
• OS Support: Windows, Linux, Android
• Operating Temperature: 0 ~ 50°C
• Dimension:
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/support/default.
aspx
This manual is for the PPC RFID 98R3P300010, Rev.
A1.
Part No. 2041C30010
Printed in China
Packing List
Before installation, ensure that the following items are
included with the product:
1. 1 x RFID module
2. 3 x Cable Clip
3. 1 x M3x5L screw
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Assembly Instructions
1. Fix the assembled module kits onto the machine using
2. Connect the USB cable to one of the available USB
1st Edition
October 2023
the existing screws. Ensure careful adjustment of the
screws to eliminate any gaps between the RFID module
and the machine, as illustrated in the following picture:
ports and secure the cable with a clip, as depicted in
the following image:
PPC-RFID_98R3P300010 Startup Manual 1
