User Manual
PPC-IPS
Intelligent Power System for PCs

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PPC-IPS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PPC-IPS

Summary of Contents for Advantech PPC-IPS

  • Page 1 User Manual PPC-IPS Intelligent Power System for PCs...
  • Page 2 The documentation and the software included with this product are copyrighted 2021 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
  • Page 3 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This type of cable is available from Advantech. Contact your local supplier for ordering information.
  • Page 4 환경에서 사용하는 경우 전파간섭의 우려가 있습니다. The power outlet socket should have a ground connection. DISCLAIMER: These instructions are provided according to IEC 704-1 standards. Advantech disclaims all responsibility for the accuracy of any statements contained herein. PPC-IPS User Manual...
  • Page 5 (將電池投入火中或 熱烤箱中，或將其機械破碎或切割，可能導致爆炸) Leaving the battery in environments with extremely high temperatures can  cause an explosion or leakage of flammable liquid or gas (將電池放置在極端高 溫的環境中，可能導致爆炸或易燃液體或氣體洩漏) PPC-IPS User Manual...
  • Page 6 PPC-IPS User Manual...

  • Page 7: Table Of Contents

    ......1 Introduction ....................2 Specifications .................... 2 Dimensions ....................3 Figure 1.1 PPC-IPS with Baseboard ........... 3 Figure 1.2 PPC-IPS without Baseboard ........3 Figure 1.3 Installation via DIN-Rail Mount ........4 Figure 1.4 DIN-Rail Bracket Dimensions ........4 Chapter Installation Instructions ......5...
  • Page 8 Chapter PPC-IPS-AE Adjustment Tool ..29 Notice of Use ..................30 4.1.1 PC Support ................. 30 UI Introduction - Basic................30 4.2.1 Select COM Port................. 30 4.2.2 Power State Selection (S4 or S5) ..........30 4.2.3 Status Indicators ................. 31 4.2.4...

  • Page 9: Chapter 1 General Information

    Chapter General Information  Introduction  Specifications  Dimensions...

  • Page 10: Introduction

    Introduction The PPC-IPS module is a lightweight intelligent power management system designed to protect panel PCs from electrical damage. During power interruptions/ fluctuations, the module can serve as a temporary power source to ensure safe shut- downs and reduce the risk of data losses. Moreover, the module can be easily installed on a DIN rail or affixed to the rear of a panel PC for easy deployment.

  • Page 11: Dimensions

    Dimensions 151.80±0.20 13.00 100.00 75.00 3.60 104.67 Figure 1.1 PPC-IPS with Baseboard The VESA mount should be affixed using M4 screws at a maximum depth of 8 mm/ 0.31 in. 151.80 32.00 100.00 75.00 DC OUT DC IN BAT Charge...
  • Page 12 Figure 1.3 Installation via DIN-Rail Mount 66.00 9.00 35.00 Figure 1.4 DIN-Rail Bracket Dimensions PPC-IPS User Manual...

  • Page 13: Chapter 2 Installation Instructions

    Chapter Installation Instructions...

  • Page 14: Introduction

    This helps to delay system shutdowns, allowing work to be finished and reduc- ing data losses. Once the shutdown delay interval has expired, the module sends a shutdown order to the PC. There are two modes for PC shutdown via PPC-IPS mod- ule - PS-ON and RS232 (refer to the figure below).

  • Page 15: Dual Auto-Shutdown Modes

    Supports max. power  No RS-232 port required  mode* Status monitoring  *In max. power mode, the PPC-IPS module optimizes power consumption to support a maxi- mum length of time based on the remaining battery capacity. PPC-IPS User Manual...
  • Page 16 A. PS_ON Mode Connect the PS_ON wire of the control cable to the PS_ON slot on the PPC mother- board. B. RS-232 Mode Connect the PPC-IPS module to the PC using the PPC-IPS control cable. PPC-IPS Shutdown Signal Diagram PPC-IPS User Manual...

  • Page 17: System I/O

    (as shown in the figures below). When placed upright, the PPC-IPS module will appear as shown in Figure 2.3. Figure 2.1 PPC-IPS Module Overview Figure 2.2 I/O Layout A.

  • Page 18: Installation Procedures

    2.4.1 VESA Mount Installation Affix a VESA mount bracket to the rear of the PPC panel PC. Install the PPC-IPS module on the mount bracket and affix in place using screws (as shown below). Figure 2.3 VESA Mount Diagram Note! VESA mount screw type: M4 Maximum screw depth: 8 mm/0.31 in...

  • Page 19: Din-Rail Installation

    Note! DIN-rail screw type: M3 Maximum screw depth: 5 mm/0.19 in After the DIN-rail bracket is secured to the PPC-IPS module, mount the bracket onto the DIN rail as shown below. Figure 2.5 Mounting the DIN-Rail Bracket PPC-IPS User Manual...

  • Page 20: Power And Control Cable Installation

    2.4.3 Power and Control Cable Installation After installation of the PPC-IPS module, connect the power and control cables. In the instructions provided below, we use an Advantech panel PC as the example device. If installing the PPC-IPS module on another type of system, connect the power cable and PS_ON cable according to the connector pin definitions.
  • Page 21 In the image shown below, the white wire is the positive pole of the adapter, and the black wire is the negative pole. Figure 2.8 Positive and Negative Poles Tighten the screws on the power cable connector to finish assembling the power cable. Figure 2.9 Assembled Power Cable and Adapter PPC-IPS User Manual...
  • Page 22 A. Shutdown through PS_ON via hardware signal Retrieve the control cable from the accessory box. Figure 2.10 Control Cable Detach the COM port cable and connector from the control cable. Figure 2.11 COM Port Cable PPC-IPS User Manual...
  • Page 23 Next, remove the affixing screws and rear cover of the panel PC. Figure 2.12 Screw Locations Break out the punch hole on the rear cover. Figure 2.13 Punch Hole Location PPC-IPS User Manual...
  • Page 24 Replace the rear cover and tighten the screws to affix it in place (refer to Sec- tions 2.4.1 and 2.4.2 for VESA and DIN-rail mounting). Figure 2.15 Installed Power Cable Connect the power and control cables to the panel PC. PPC-IPS User Manual...
  • Page 25 For PS_ON shutdown mode, the power button must be configured to shutdown the system or initiate sleep mode (refer to Chapter 3 for set- tings). B. Shutdown through RS-232 via software utility Retrieve the control cable from the accessory box. Figure 2.17 RS-232 Cable PPC-IPS User Manual...
  • Page 26 Connect the power cable and control cable to the panel PC. Figure 2.19 Connected Power and Control Cables Note! For RS-232 shutdown mode, the PPC-IPS power management software must be installed (refer to Chapter 4 for software setup). PPC-IPS User Manual...

  • Page 27: Module Installation

    Module Installation In the instructions provided below, a VESA mount is used as the demonstration example. Remove the 4 screws located on both sides of the PPC-IPS module (circled in red below). Figure 2.20 Module Screw Locations Remove the PPC-IPS module baseboard.
  • Page 28 Attach the baseboard to the rear of the panel PC using 4 screws provided in the accessory box. Figure 2.22 Baseboard Screw Location Affix the PPC-IPS module to the baseboard securely using the 4 screws removed in Step 1. Figure 2.23 PPC-IPS Module at Rear...

  • Page 29: Replace The Ips Battery

    2.4.5 Replace the IPS Battery Remove the affixing screws on the top cover of the PPC-IPS module (circled in red below). Figure 2.24 Top Cover Screw Locations Open the top cover and remove the cable connector. Replace the existing battery with a new battery and connect the battery cable connector.
  • Page 30 PPC-IPS User Manual...

  • Page 31: Chapter 3 Ips Settings

    Chapter IPS Settings I/O Connector Specifications...
  • Page 32 The Time switch is used to set the waiting period (30s/360s) before sending the PS_ON signal to shut down PC after AC power is off. Warning! During this time the PPC-IPS will supply the PC with its battery to ensure the loading PC works properly.

  • Page 33: Ps_On Shutdown Mode

    Note! RS-232 is used to control the PPC-IPS module via AP. If the user does not use AP to control the module, RS-232 should not be con- nected. When PC PS_ON is set as the shutdown mode, avoid interruptions to PS_ON signals caused by program operations.
  • Page 34 Click Control Panel. In the Control Panel, click on Hardware and Sound. PPC-IPS User Manual...
  • Page 35 Click on Change what the power buttons do to access the System Settings. In System Settings, click on the dropdown menu to access the various options. PPC-IPS User Manual...
  • Page 36 Select Shutdown. Then click on Save changes to save your changes and complete the configura- tion. . PPC-IPS User Manual...

  • Page 37: Ppc-Ips-Ae Adjustment Tool

    Chapter PPC-IPS-AE Adjustment Tool...

  • Page 38: Notice Of Use

    UI Introduction - Basic 4.2.1 Select COM Port Select the COM port to be connected to the PPC-IPS module. 4.2.2 Power State Selection (S4 or S5) This option allows users to set the system power status as hibernation (S4) or shut- down (S5) when the PPC-IPS module is activated.

  • Page 39: Status Indicators

    4.2.3 Status Indicators Status indicators provide a convenient way to determine the PPC-IPS module status/ activity. green indicates normal status and red indicates abnormal status Host PPC: indicates whether the AP is connected with the panel PC correctly DC-In: indicates whether the DC power source is active Battery: indicates whether the battery is functioning normally 4.2.4...

  • Page 40: Ui Introduction - Advanced

    4.3.3 Time to Turn-Off IPS after Shutdown Command This option allows users to configure the time before turning off the PPC-IPS module after a shutdown/hibernate signal is sent to the panel PC to protect the battery life. The time interval can be between 1 and 9 minutes.
  • Page 41 PPC-IPS User Manual...
  • Page 42 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2021...
