PPC-300 RFID Module
Startup Manual
Packing List
Before card installation, please ensure that the following
items have been included in your shipment:
1. 1 x PPC-300 RFID module
2. 3 x Strain Releef Bushing
3. 1 x M3 x 5L screw
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Ordering Information
PN
Description
98R3P300000
RFID Reader, Black, for PPC-300
Software Installation
Before installing software on the RFID module, install the
corresponding drivers to ensure full functionality.
All drivers can be downloaded from the Advantech website
at http://www.advantech.com.
For more information about this or other Advantech
products, visit our website at
http://www.advantech.com
For technical support and service, visit our support
website at
http://support.advantech.com
This manual is for PPC-300_RFID, Rev. A1.
Part No. 2043776001
Printed in China
• Interface: USB
• Cable Length: 50cm
• Frequency: 13.56 MHz
• RFID R/W Mode: Support ISO15693, ISO14443A/B,
• NFC: Support NFCIP-1 (ISO 18092), NFCIP-2 (ISO/
• NFC Card Mode: Simulates ISO14443A/B mode
• NFC R/W Mode: Support Type 1/2/3/4
• OS Support: Windows XP/7/8
• Dimensions: 101 x 37 x 25 mm
• Operating Temperature: 0 ~ 40° C
Edition 1
February 2023
Appearance
Specifications
Felica, Mifare Ultralight
IEC21481)
PPC-300_RFID Startup Manual 1
