For cameras with audio input, microphone built-in, or audio output, click the "Audio" tab to go to the
interface as shown below.
• Audio Encoding: Select the audio encoding from the drop-down menu. G711A and G711U are selectable.
• Audio Type: If the camera has a built-in microphone, select to enable audio input from the microphone
or external audio input (LIN).
4.2.3

OSD Configuration

The OSD settings page allows users to set up a text overlay on the video, showing the date and time, device
name, etc.
To set a timestamp, device name, or OSD content and picture overlap, check the box next to each field. For the
time stamp, select the date and time format you wish to use. For all other settings, enter the text that will appear
over the camera's video. Once enabled, users can click-and-drag the text frames to the desired position on the
camera's preview screen. Click the "Save" button to save the settings.
-17-
