hager 4501 Installation Instructions Manual

When unauthorized egress is initiated by depressing the push pad of the 4501 OBDE, an audible alarm will sound and
an irreversible unlock delay period of 15 seconds will begin. Meanwhile, the person exiting must wait to egress, allowing
personnel or security time to respond to the alarm. After the delay period has expired, the device unlocks, permitting
egress until the device is reset. In a life safety emergency, the device will immediately unlock upon loss of power or
when powered by a fire control supervised power supply. The included signage provides clear and comprehensive
instructions of the door egress operation for persons without prior knowledge of the exit delay, including the sight and
hearing impaired.
4501 OBDE Applications include:
Restricting the egress of wandering patients for their own safety.
•
Restricting the egress of commercial center patrons for security application needs.
•
Controlling pedestrian traffic in transportation facilities, including airport jetways and tarmacs
•
Reducing shoplifting and employee theft
•
Standard Features:
Egress Delay
15 second exit delay
•
1 or 2 second nuisance delay
•
Optional 30 second delay with AHJ approval
•
Built-In Visual & Audible Annunciation
Armed mode
•
Nuisance mode
•
Irreversible egress mode
•
Release mode
•
Trigger Modes
Egress alarm triggered by Push Bar
•
Trigger input from external device (Pair of Doors)
•
Door opened in secure mode (Door Forced or Prop)
•
Code Compliance
IFC International fire Code
•
IBC International Building Code
•
NFPA 101 Life Safety Code
•
NFPA 1 Uniform Fire Code
•
California Building Code with the exception of Sec. 11B-309.4 2013 edition.
•
Field selectable automatic or manual power up after emergency release or power loss.
•
Use of manual power up complies with California Building Code (OSHPD) requirements.
Rev 1, Rev Date: 9/28/19
4501 On-Board Delayed Egress Exit Device
Rim Mount, Concealed Vertical Rod, Vertical Rod, or
PUSH UNTIL ALARM
SOUNDS. DOOR CAN BE
OPENED IN 15 SECONDS.
Always visit www.hagerco.com for the latest Installation Instructions
HAGER COMPANIES 139 Victor Street, St. Louis, MO 63104 • (800) 325-9995
4501 On-Board Delayed Egress Installation
Mortise Exit Device
Control Inputs
Field-selectable 1 to 30 second request-to-exit with anti-tailgate
•
and door prop alarm.
Bypass
•
Reset
•
Remote trigger (for Pairs of Doors)
•
DPS (Required for Door Forced, Prop and Anti-Tailgate)
•
Monitoring Outputs
Secure/Unsecure status
•
Egress initiation status
•
Released/Bypass status
•
Recommended Accessories
4501 DE – Delayed Egress Slave Exit Device
•
(for Pair of Doors)
2900 Series regulated & filtered power supply –
•
2908 (1 Amp) or 2909 (2 Amp)
Door contact (included) – 2-679-0626 magnetic switch
•
Power Transfer Device – ETW/ETM/EPT
•
Instructions
I-EA00156
