hager 3221 Installation Instructions

F OR USE ON DOORS 1-3/8" to 1-3/4"
(35mm-45mm) THICK
TOOLS REQUIRED FOR NEW INSTALLATION:
(1) Phillips Head Screwdriver
(1) 2-1/8" (54mm) Hole Saw
(1) 1" (25.4mm) Drill Bit
(1) Chisel
TOOLS REQUIRED FOR REPLACEMENT INSTALLATION:
(1) Phillips Head Screwdriver
FOR REMODELING OR NEW CONSTRUCTION:
- Follow all steps
DOOR EDGE
DOOR EDGE
1. MARK DOOR
DOOR EDGE
DOOR FACE
1"(25.4mm) HOLE
1"(25.4mm) HOLE
4-1/8"(105mm)
4-1/8"(105mm)
Measure center line of lock; height as desired from finished floor.
DEEP
Select 2-3/4" or optional 2-3/8" backset, fold and apply template
to interior side of door and mark center of door as indicated on
template. Mark center hole on door face through guide on template.
2-1/8" (54mm) HOLE
1"(25.4mm) HOLE
(See Step 7 for changing latch backset)
1-3/16" (31mm) DEEP
4-1/8"(105mm)
3. PREP DOOR
a.
Insert latch in hole, keeping latch face parallel to
face of door edge.
Mark outline and remove latch.
TEMPLATE
T E MP L A T E
FOLD HERE
ON DOOR EDGE
45
1-9/16"
1-3/4"
Make 1"(25.4mm) hole at center
of door edge.
HAGER COMPANIES139 Victor Street, St. Louis, MO 63104 (800) 325-9995 FAX (800) 782-0149
LATCH MOUNTING PLATE
THUMB TURN
ASSEMBLY
DOOR FACE
DOOR FACE
DEEP
2-1/8" (54mm) HOLE
1-3/16" (31mm) DEEP
DEEP
2-1/8" (54mm) HOLE
b.
1-3/16" (31mm) DEEP
Chisel 5/32" (4 mm) deep or
until latch face is flush with door edge.
2-1/8" (5 mm) HOLE 4
2-3/8" ( 60mm ) BACKSET
2-3/4" ( 70mm ) BACKSET
40 35
1-3/8"
CAUTION ：
DO NOT DRILL 2-1/8" (54mm) HOLE
THROUGH TO OPPOSITE SIDE OF DOOR .
(READ INSTRUCTIONS CAREFULLY)
3221 Thumbturn Only Deadbolt
LATCH
DOOR EDGE
MOUNTING SCREWS
2. DRILL HOLES
1"(25.4mm) HOLE
4-1/8"(105mm)
Drill 1" (25.4 mm) hole 4-1/8" (105 mm) deep in center of door edge.
Drill 2-1/8" (54mm) hole 1-3/16" (31 mm) deep on interior door face.
CAUTION:
Do not drill completely through the door face.
c.

Installation Instructions

DEADBOLT
STRIKE
WOOD FRAME
REINFORCER
DUST BOX
DOOR FACE
DEEP
2-1/8" (54mm) HOLE
1-3/16" (31mm) DEEP
Refer to Step 5 & 6 when installing latch.
7/28/08
