Maxxus BENCH PRESS PRO Installation & Operating Manual page 6

Assembly Step 3
Lock Back cushion (No.6) and Head cushion(No.7) into
Pre-assembled part assembly (B) with 8pcs External hexagon
screw M8*20 (No.11) 1pcs External hexagon screw M8*60
(No.13) and 9pcs Flat washer φ8 No.12
as shown in the picture.
13
Step 4
11
Assembly Step 4
Lock 4pcs of Pre-assembled part assembly (C) into 2pcs of Pre-assembled part assembly (A) with 8pcs External
hexagon screw M10*100 (No.10) 16pcs Arced washer φ10 (No.15) and 8pcs Locking nut M10( No.16) as shown in
the picture.
15
16
Lock Back cushion（No.6 ）and Head cushion （No.7 ） into Pre- assembled part assembly（B） with 8pcs
External hexagon screw
（No.12 ） as shown in the picture.
C
15
16
Assembly
6
13
13
11
11
15
M8*20 (No.11 )，1pcs External hexagon screw
10
10
15
7
13
11
M8*60 (No.13 ) and 9 pcs Flat washer
15
10
10
15
6
13
12
φ8
15
16
16
15
C
