Carefully unpack all delivered parts. Have someone there to help you as some of the training device parts are
bulky and heavy.
Assemble the parts carefully as any damages or defects occurring due to mistakes made at the time of assem-
bly are not covered by the warranty or guarantee. Therefore, read through the assembly instructions carefully
before you start assembling, follow each assembly step exactly as described and keep to the correct sequence
of assembly as instructed.
Assembly of the training device must be carried out thoroughly by an adult person only.
Assemble the training device in a location which is level, clean and clear of obstructions. 2 people are required
to carry out the assembly.
For this reason, always be careful and thorough in your actions when assembling this device.
Make sure that the parts necessary for each stage of assembly are initially only hand tightened together. Only
Training can only start when the training device has been fully and correctly assembled.
Note:
As some of the components may have sharp edges, please wear suitable protective gloves during the entire
assembly process.
Assembly Step 1
Step 1:
Remove all components from the packaging.
Mark the drill holes on the wall where the HomeGym H1 is to be mounted. Make sure in advance that the wall is
suitable.
Only use wall plugs and screws which are suitable for the particular type of wall you are mounting the Hom-
eGym H1 to. Consult a specialist builder or your DIY store if you are in any doubt.
To mark the drill holes exactly in the right place on the wall, we recommend you place the base frame of the
HomeGym H1 against the wall in the appropriate place. Be sure to ask one or two other people to help you. Use
a spirit level to check that the HomeGym H1 is level before you mark the holes.
Once it is level, drill the holes in the wall.
