10 Power Supply and Panel Connections
Connections between probes and panels must be as shown in the following diagrams. Never alter their length or cross-section without
first consulting your authorised distributor.
CCONNECT PH/ORP_LINE
ORP
pH
FLOW
SWITCH
TEMPERATURE
SENSOR
CCONNECT PH/ORP_PRO
ORP
pH
ORP
pH
INDUCTIVE
SENSOR
TEMPERATURE
SENSOR
32
CCONNECT PH/PPM_PRO
pH
pH
INDUCTIVE
SENSOR
TEMPERATURE
SENSOR
PPM
PPM
