FlexStyle Cassette Battery
®
Section 5 - RF Remote Programming Instructions
Pen
Programming
Button
BACK
SHADE
Pen
Programming
Button
BACK
Help Me
Help Me by Somfy
guides you step-by-step when installing
Somfy products. All programming
instructions are available in a single
smartphone application available on
GooglePlay and the Apple
®
1. Select a transmitter channel to assign motor. Hold UP and DOWN buttons
until motor jogs, then release.
2. Check motor direction. To reverse motor direction, hold MY/STOP button
for 5 seconds until motor jogs. Check direction again.
3. Move motor to upper limit position. Hold MY/STOP and DOWN buttons
UP
until motor moves down, then release. Use UP and DOWN buttons to move
STOP
shade to correct lower limit and press MY/STOP.
DOWN
4. While motor is at lower limit, hold UP and MY/STOP buttons until motor
LED Lights
moves up, then release. The shade should move to upper limit and stop.
Channel
Selector
5. Next, hold MY/STOP button until motor jogs.
6. Put motor into USER MODE by briefly pressing small programming button
on the back of the transmitter. Motor will jog.
7. If programming additional shades on the same channel, put this motor
to sleep until all motors on the same channel are programmed. To put to
sleep, hold button on motor head for one jog, release. Then hold UP/STOP/
DOWN all at the same time and wait for shade to jog. Motor is now asleep.
8. To wake motor up after putting to sleep, hold button on motor head for 1
second. Shade will jog to indicate it is now awake.
Setting an Intermediate Stop -
Shade MUST BE in USER mode.
1. Move shade to desired mid-point location
and hold MY/STOP button until motor jogs.
2. To test, press the MY/STOP button when
motor is standing still. The shade will move
to that intermediate location.
3. To delete an intermediate stop, go to the
intermediate stop and hold the MY/STOP
button until motor jogs.
Add a Channel -
Shade MUST BE in USER mode.
1. Select channel currently operating
motor, then hold programming button
until motor jogs.
2. Select new channel to add to motor,
then hold programming button until
motor jogs.
3. The motor should now work on both
the old and new channel.
is an application that
®
App Store.
®
SHADE SHADE
upper
or
lower
limit
Delete a Channel -
Shade MUST BE in USER mode.
1. Select channel operating motor
that you want to keep, then hold
programming button until motor jogs.
2. Select channel to remove, then hold
programming button until motor jogs.
Motor should now only work
on channel kept from Step 1.
page 5 of 8
SHADE
SHADE
Adjust Limits in User Mode
1. Move motor to limit
(upper or lower)
to be changed. Shade must move
to previously set limit and will stop
automatically.
2. Hold UP and DOWN buttons until
motor jogs.
3. Move motor to its new limit location
and hold MY/STOP button until
motor jogs.
Reset Motor
1. Hold button on motor
head and wait for
3 jogs. Motor is now
reset.
