Intense PRIMER 29 EXPERT Manual page 10

F
S T E P 4 C O N T I N U E D . . .
Once everything is lined up and in position, reinsert
the axle and tighten using the integrated lever on the
non-drive side (left), turning clockwise until tight (F).
Reinstall the lever within the axle by pushing it firmly
back in place. Then with a 5mm Allen key on the drive
side of the bike tighten the axle and torque to 11Nm
(G) .
You can now take the lock off the rear derailleur (H).
To do this, gently push the derailleur cage forward
a little and the cage lock will automatically release.
Slowly let the derailleur arm move backwards into
position.
G H
