9 Specifications and assembly accessories

9 Specifications and assembly accessories
9.1

Technical data

Electrical data
Supply voltage U
B
(polarity reversal protection,
overvoltage protection)
Maximum current consumption
Communication interface
Mechanical data
Housing material
Housing dimensions (not including connector)
Weight (without cable, without connector)
Cable data
Cable material
Cable diameter
Core cross section
Minimum bending radius static/dynamic
Connections
Sensor connection
Ambient data
Operating temperature range
Storage temperature range
Maximum relative air humidity
Degree of protection
Dielectric strength
EMC
Vibration resistance
Shock resistance
Approvals
European Economic Area
Data measuring system (linear sensor and magnetic tape)
Measuring method
Resolution
Maximum measuring range
Maximum positioning speed
(1)
Sensor distance
56
Technical data
+20 V to +30 V DC
150 mA
SG: SSI Gray
Zinc die casting
70 mm × 16 mm × 30 mm
≈ 50 g
TPE-U (PUR)
6.4 mm ± 0.2 mm
2
6× 0.25 mm [24 AWG]
5 ×/10 × cable diameter
8-pin male connector M12, A-coded
-10 °C to +70 °C
-20 °C to +85 °C
95 %, non-condensing
IP 65; as per DIN EN 60529:2014-09
500 V AC; as per DIN EN 61439-1:2012-06
EN 61000-6-2:2005, EN 61000-6-4:2007
2
1 to 100 m/s , (5 to 15 Hz);
2
1 to 100 m/s , (15 to 159 Hz);
as per DIN EN 60068-2-6:2008-10
2
800 m/s , 6 ms,
as per DIN EN 60068-2-27:2010-02
Conformity in accordance with
EMC Directive 2014/30/EU
contactless, magnetic-absolute
10 μm
10 m
4 m/s
1.5 mm
