- Page 1 Instructions for Use StatSpin Express 2 Centrifuge Model Number M501-22 This manual is intended for SSX2 - Express 2 for 100 to 240 VAC, 50/60 Hz 55-003910-001FD September 2018 Beckman Coulter, Inc. 250 S. Kraemer Blvd. Brea, CA 92821 U.S.A.
- Page 2 Trademarks Beckman Coulter, the stylized logo, and the Beckman Coulter product and service marks mentioned herein are trademarks or registered trademarks of Beckman Coulter, Inc. in the United States and other countries. All other trademarks are the property of their respective owners.
- Page 3 • Updated: Manufacturer address, Warning and Cautions, Limited Warranty statement • Deleted: CE, and EC Rep 55-003910-001 FB, 9/2016 • Converted the Express 2 Operator's Manual to a Beckman Coulter Instructions for Use (IFU) • Made general clarifications to the IFU •...
- Page 4 Revision History 55-003910-001FD...
- Page 5 Safety Notice Read all product manuals and consult with Beckman Coulter-trained personnel before you operate the system. Do not perform any procedure before you carefully read all instructions. Always follow the product labels and the manufacturer’s recommendations. If you have any questions: •...
- Page 6 Handle and dispose of sharp fragments according to the World Health Organization's Laboratory Biosafety Manual and relevant local and national regulations. Warning If the equipment is used in a manner not specified by Beckman Coulter, the protection provided by the equipment may be impaired. Warning Inspect the instrument for cracks or any physical damage to housing, cover, and rotor upon the receipt of the unit.
- Page 7 Warning Only use the external power supply (Beckman Coulter Part Number B95657) included with the centrifuge. This power supply is only for use with centrifuges that have a marked input current rating of 3A (shall not be used on units rated 1.7A). Use of any other external power supply can cause damage to the centrifuge and will void the warranty.
- Page 8 Safety Notice Warnings and Cautions • Do not use mobile or cordless telephones and transceivers in the same room as the system. • Do not use medical equipment that can be susceptible to malfunctions caused by Electric Magnetic Field (EMF) near the system. Caution Disconnect the power cord of the external power supply from the electrical outlet before performing maintenance or inspection.
- Page 9 Safety Notice Warnings and Cautions Caution Replace Tube Insert immediately if a tube breaks during centrifugation. Wear Personal Protective Equipment (PPE) such as gloves, eye shields, and lab coats. Caution Running the centrifuge repeatedly with an unbalanced load condition can cause excessive vibrations and premature equipment failure.
- Page 10 Safety Notice Symbols and Definitions Symbols and Definitions Table 1 Express 2 Symbols Glossary Symbol Description Warning; Biological hazard To warn of a biological hazard. IEC 60878. Graphical Symbols for electrical equipment in medical practices. #7010-W009 Supplemental Product-Specific Manufacturer Information This label indicates a caution to operate only with all covers in position to decrease risk of personal injury or biohazard.
- Page 11 For Beckman Coulter products bearing this label, contact your dealer or your local Beckman Coulter Representative for more information on the take-back program that facilitates the correct collection, treatment, recovery, recycling, and safe disposal of these products.
- Page 12 Safety Notice Symbols and Definitions Table 1 Express 2 Symbols Glossary (Continued) Symbol Description RoHS Caution Symbol This symbol indicates that this electronic information product contains certain toxic or hazardous elements, and can be used safely during its environmental protection use period. The number in the middle of the logo indicates the environmental protection use period (in years) for the product.
- Page 13 Safety Notice Symbols and Definitions Table 1 Express 2 Symbols Glossary (Continued) Symbol Description Direct current To indicate on the rating plate that the equipment is suitable for direct current only; to identify relevant terminals. IEC 60417: Graphical symbols for use on equipment - Overview and application, #5031 Date of Manufacture To indicate the date when the medical device was manufactured.
- Page 14 Safety Notice Symbols and Definitions Table 1 Express 2 Symbols Glossary (Continued) Symbol Description California Proposition 65 This product can expose you to chemicals known to the State of California to cause Cancer and Reproductive Harm. For more information go to https://www.P65Warnings.ca.gov.
-
Page 15: Table Of Contents
Contents Revision History, iii Safety Notice, v CHAPTER 1: Installation, 1-1 Inspecting the Packaging, 1-1 Confirming the Contents, 1-1 Installing the System, 1-1 Connecting the Power, 1-1 CHAPTER 2: System Overview, 2-1 Intended Use, 2-1 Operator Controls, 2-1 Error Indicators, 2-2 Accessories, 2-3 CHAPTER 3: Operating... - Page 16 Contents 55-003910-001FD...
-
Page 17: Installation
• One centrifuge rotor (Product No. RTX4A) • Four rotor inserts for 13x75-mm tubes (Product No. SV01) • One external power supply (Beckman Coulter Part No. B95657) • One grounded power cord (for North American use only) • One Instructions for Use •... - Page 18 Warning Only use the external power supply (Beckman Coulter Part Number B95657) included with the centrifuge. This power supply is only for use with centrifuges that have a marked input current rating of 3A (shall not be used on units rated 1.7A). Use of any other external power supply can cause damage to the centrifuge and will void the warranty.
-
Page 19: System Overview
CHAPTER 2 System Overview Intended Use The StatSpin Express 2 is a microprocessor controlled, high-speed bench top centrifuge designed to rapidly separate whole blood in the original evacuated or syringe type collection tubes. The four-place 30° angle rotor included with the centrifuge is designed to provide rapid separation while minimizing potential re-suspension of cells. -
Page 20: Error Indicators
To stop the beeps, press the Stop button. Error/Service light will continuously illuminate when the centrifuge has achieved a total run time of 150 hours, which is the useful life of the drive system. Drive mechanism needs replacing. Contact Beckman Coulter Customer Support. 55-003910-001FD... -
Page 21: Accessories
System Overview Accessories Accessories Table 2.2 Accessories Product No. Description SV01 Inserts compatible with 5mL (13 x 75 mm or 10.25 x 82 mm ) blood collection tubes. 4 inserts / package SV02 Inserts compatible with 3mL (10.25 x 64 mm) blood collection tubes. 4 inserts / package SV05 Inserts for 1.5-2 mL microtubes, 10.25 x 47 mm, and BD Microtainers. - Page 22 System Overview Accessories 55-003910-001FD...
-
Page 23: Operating Instructions
CHAPTER 3 Operating Instructions Opening and Closing the Cover To close the lid, firmly apply pressure on the cover directly above the latch until the gasket compresses completely and the latch engages with the cover. The electrically operated cover interlock mechanism prevents operation until the cover is completely closed and locked, and prevents the cover from being opened while the centrifuge is in operation. -
Page 24: Reinstalling The Rotor
Operating Instructions Spinning the Sample Reinstalling the Rotor Caution Never operate the centrifuge without the rotor properly mounted and the locking nut tightened. Failure to install and secure the rotor correctly can damage the centrifuge. Remove the tube inserts from rotor. Place rotor on rotor holder, being sure the two mounting pins on the rotor holder are aligned with two of the four small holes near the center of the rotor. -
Page 25: Unloading
Operating Instructions Spinning the Sample Be sure that the correct tube inserts are installed. The Express 2 centrifuge is provided with four tube inserts for 13 x 75 mm tubes (Product No. SV01). Other sizes are available. For more information, refer to Accessories. Two or four tubes can be processed simultaneously. - Page 26 Operating Instructions Spinning the Sample 55-003910-001FD...
-
Page 27: Maintenance
Maintenance Overview Beckman Coulter recommends that instrument operators perform periodic inspections and preventative maintenance on all devices. Contact Beckman Coulter at any time if the instrument is not functioning correctly. Caution Disconnect the power cord of the external power supply from the electrical outlet before performing maintenance or inspection. -
Page 28: Disinfecting The Rotor
Do not defeat any safety interlocks while performing the test. If the StatSpin Express 2 fails to achieve an operating speed of 8,500 rpm ±5% in the 120s and 180s settings, contact Beckman Coulter Customer Support. 55-003910-001FD... -
Page 29: Troubleshooting
Chapter 3 to open the cover and retrieve samples, then contact Beckman Coulter Customer Support. Service Refer all service to qualified service personnel or Contact Beckman Coulter Customer Support at 1-800-854-3633. Be sure to complete and return the warranty card as directed. - Page 30 Representations and warranties made by any representatives, salespersons or agents of Beckman Coulter, which are inconsistent or in conflict with or in addition to the terms of this Agreement, will not be binding upon Beckman Coulter unless reduced to writing and approved by an expressly authorized officer of Beckman Coulter.
-
Page 31: Appendix A: Specifications
APPENDIX A Specifications Specifications Product Number SSX2 Model Number M501-22 Speed 8,500 rpm ± 5% Force 4,440 x g Cycle Times 30s: 30 seconds 120s: 120 seconds 180s: 180 seconds Acceleration Time Approximately 20 seconds Deceleration Time Approximately 25 seconds Electrical 24Vdc, 3.0A Includes switching power supply for 100 to 240 VAC, 50/60 Hz Dimensions... -
Page 32: Specifications
Specifications Specifications 55-003910-001FD... -
Page 33: Appendix B References
APPENDIX B References References 1. CLSI. “Protection of Laboratory Workers from Occupationally Acquired Infections; Approved Guideline-Second Edition.” CLSI document M29-A4 [ISBN 1-56238-453-8]. CLSI, 940 West Valley Rd, Suite 1400, Wayne, Pennsylvania 19087-1898 USA, 2001. 2. CDC. Recommendations for prevention of HIV transmission in health care settings. MMWR (Suppl. -
Page 34: References
References References 55-003910-001FD... - Page 36 © 2018 Beckman Coulter, Inc. All Rights Reserved.
