PowerWalker VFI LICR IoT Series User Manual page 34

Model name
Short-circuit
Bypass mode
current (RMS)
Normal/Battery
/protect time
mode
Voltage
Battery
Capacity (AH)
Material
Maximum EBM quantity
EBM auto detection
Battery Hot swappable
Charging method
Charger Charging current
Recharging time
Other mode CVCF
Display
Language
USB
RS232
Dry in/out
RPO
HMI
Intelligent slot
Network card
Modbus card
Dry contactor card
Wireless module
IOT Ethernet port
Monitor software
Dimension
(W*D*H) mm
Physical
IP protection level
performance
Plug solid
Wheel
Operating
temperature
storage temp
Environment
Relative Humidity
Operating Altitude
Acoustic Noise
UPS
Certification
EBM
Conduction
EMI
/Radiation
ESD
RS
EMS
EFT
Surge
1K 1.5k
550A/2.8ms
20A/100ms
48VDC
9Ah
Lithium iron phosphate (Li-FePO4)
4
Yes
Yes
BMS
1.5A
3.7h to 90%
Yes (derating to 60% load)
Dot matrix LCD (optional segment LCD)
Multi-Language
USB 2.0 with HID power device
Yes (DB9)
1 programmable dry in; 1 programmable dry out
Yes
Yes (for long card)
Optional, NMC long card
Optional, CMC Long Card
Optional, AS400 Long Card
Optional
RJ45
Winpower, Winpower View APP
438*445*85.5(2U)
IP20
Optional
No
0-40°C
0 to 40°C (32 to 104°F) with batteries
-25 to 55°C (5 to 140°F) without batteries
0-95%
0~3000m (the load derating 1 % every up 100m @1000~3000m)
<45dB at front 1m
CE/CB,IEC62040, UN38.3
IEC62619,UN38.3,UL1973 compliant
C2
IEC/EN 61000-4-2
IEC/EN 61000-4-3
IEC/EN 61000-4-4
IEC/EN 61000-4-5
28
2K 3K
699A/7ms 699A/7ms
36A/100ms 54A/100ms
76.8VDC 76.8VDC
9Ah 9Ah
1.5A 1.5A
4.6h to 90% 4.6h to 90%
438*600*85.5(2U)
<50dB at front 1m
