ionode4 – Hardware User Guide
•
•
Network
Network connection availability check:
•
•
•
NOTE: The indicator is not available until all services are in operation.
Signal
Green LED lights up if DSP and the design are running, else LED lights up red.
NOTE: The indicator is not available until all services are in operation.
Outputs
Green LED lights up if at least one output contact is closed.
NOTE: The indicator is not available until all services are in operation.
Inputs
Green LED lights up if at least one input contact is closed.
NOTE: The indicator is not available until all services are in operation.
Switched
Reserved for future use.

DEVICE CONFIGURATION AND SETUP

First connect your device to the power supply using a suitable, secure jack plug. In a second step, connect the device to
your network with a LAN cable and then establish the network connection. Access the nnounce configuration UI to define
the LAN setup for your device. If you are incorporating the ionode4 device within a Q-SYS installation, perform further
steps in the Q-SYS designer and download the ionode4 plugin.
Connect the Device
Connect your ionode4 device to the power supply with a jack plug and to your network with a data communication cable
CAT5 with a RJ45 connector.
NOTE: Use the LAN B port for a secondary connection if required.
1. Connect the device to power – use a
2. Connect the device to the network, with a DHCP enabled
connector.
3. Use a computer with an Internet browser and search for your ionode4 device by typing the URL
https://ionode4-
product sticker of your device.
•
Example: https://ionode4-000000 or https://ionode4-000000.local
•
IMPORTANT: Instead of 000000, enter the last 6 digits of the MAC address found on your
ionode4 device.
•
NOTE: The device is using mDNS.
4. Your web-browser shows the login page of your ionode4 device.
TM
nnounce by Simpleway
Yellow LED light indicates that the operating system successfully booted and services are
starting.
Green LED light indicates all services are up and running.
LED light is off, no network connection.
Blue LED light when auto mode active and no IP obtained from DHCP. Device available only
through IPv6 link local.
Green LED light when at least one active interface is available with correct IP address.
barrel secure jack power
and the last 6 digits of the MAC address of your device, which you can find on the
NN_USER_GUIDE_ionode4_v2.2.docx
connector.
data communication cable CAT5 with a RJ45
