ionode4 – Hardware User Guide

TECHNICAL SPECIFICATIONS

Audio AD Converter: 24 Bit @ 48 kHz 125 dB-A Dynamic Range - 0.00x % THD+N
Max input level 18 dBU / 6.16 Vrms
Crosstalk (1 kHz) - 60 dB
Input impedance 20 kΩ balanced
CMRR 60 dB
DA Converter: 24 Bit @ 48 kHz 115 dB-A Dynamic Range - 0.00x % THD+N
Max output level 7.6 Vrms
2.5 ms end to end latency
AES67 network audio (with optional encryption)
Connectivity:
4 x Balanced input channels
4 x Balanced output channels
Audio input and Output connectors can be wired in redundant wiring with standby unit
4 x Supervised control inputs (0-12 V input tolerance, 12 Vref)
4 x Control outputs (Relay NC, NO, COM pins)
1x USB-C
2 x LAN RJ45 1000 Mbs with PoE
DSP
Built-in web-based graphical DSP pipeline designer
60+ Component library
Extended precision fixed point processing
API library
User Interface
Front panel diagnostic LEDs
Rear panel diagnostic LEDs
Web-based interface
Cloud-connected
Security
Secure boot
Encrypted firmware
Tamper sensing
Secure enclave chip
AES256-GCM encryption for AES67
Storage
Onboard microSD card slot
Environmental
Operating temperature range 32 °F – 122 °F (0 °C – 50 °C)
Storage temperature range 14 °F to 140 °F (-10 °C – 60 °C)
Power
12 V DC secure jack
IEEE 802.3af power over Ethernet (PoE)
Dimensions
210 mm (W) x 275 mm (D) x 40 mm (H)
1 510 kg without mounting kit
Accessories
Mounting kit
