- Page 1 ARDWARE SER GUIDE ionode4 – Audio Integration Device ©Nnounce powered by Simpleway Keep this manual for future reference...
-
Page 2: Important Safety Instructions
• Operating temperature of the device - range 32°F – 122°F (0°C–50°C), storage temperature - range 14°F to 140°F (-10°C–60°C). • Power should only be supplied over IEC 10 A Connector, 100-240 VAC @ 50-60Hz. • Relative humidity range during storage: 10% to 85% humidity (non-condensing). nnounce by Simpleway... - Page 3 • ICES-003:2020-10 • EN 55032:2015 / DIN EN 55032:2015/A11:2021 Electromagnetic compatibility of multimedia equipment – Emission Requirements / (CISPR 32:2015/AMD1:2019) • ENT 55035:2017 / DIN EN 55035:2017/A11:2022 Electromagnetic compatibility of multimedia equipment – Immunity requirements / (CISPR 35:2016) nnounce by Simpleway...
-
Page 4: Optional Accessories
4 Clear anti-scratch rubber feet • 2 Rack mount brackets • 3x terminal block connectors with 12 positions • 1x terminal block connectors with 9 positions Optional accessories • Optional: Connection plate with 4 screws for rack mounting in pair nnounce by Simpleway... - Page 5 7. Control LEDs • inputs 8. Reset button • 9. LAN A with PoE outputs 10. LAN B with PoE The product sticker on the bottom of the device contains the MAC address required for device pairing. nnounce by Simpleway...
-
Page 6: Device Configuration And Setup
4. Your web-browser shows the login page of your ionode4 device. 5. Enter credentials into the nnounce configuration user interface: IMPORTANT: Default credentials are admin/simpleway, default PIN code is 23646. You can now access the device configuration settings and continue with the interface configuration. nnounce by Simpleway... - Page 7 NOTE: Navigate backwards or cancel your steps with the Back function in your browser. A. Navigate to Interfaces section in the left menu. Two LANs A and B can be pre-configured here, see rear panel ports. B. Configure the interface in the Manual mode or Auto mode (DHCP). nnounce by Simpleway...
- Page 8 LAN adapter. • server and Search domains are assigned by the DHCP server. D. Advanced slider allows you to insert an advanced configuration. • CIDR notation. Click on the Save Changes button to confirm the configuration. nnounce by Simpleway...
- Page 9 • Edit mode. • View mode is available after the design is deployed using the Deploy design button. Audio meters and component controls are active in this mode. Return to edit mode using the Edit design button. nnounce by Simpleway...
- Page 10 RX stream – receives audio from other devices, input. One stream can have 1 – 8 channels. IMPORTANT: To fully configure network streams, network inputs and/or network outputs must be included in the DSP design, and the DSP design itself must be saved and deployed. nnounce by Simpleway...
-
Page 11: Network Stream
The ionode4 audio integration device is connected to the network via a standard ethernet cable. This network consists • Q-SYS Core + Q-SYS peripherals, • Windows-based computer for Q-Sys designer network setup, not required for runtime operation, • Gigabit Ethernet Switch with PoE ports. nnounce by Simpleway... - Page 12 The ionode4 device is compatible with the Q-SYS ecosystem. To integrate the device, use the ionode4 plugin for Q-SYS Designer so that you can then set up the device’s properties. 1. Nnounce ionode4 plugin for Q-SYS Designer can be obtained: a. Plugin Q-Sys marketplace, b.
- Page 13 See the relevant chapter below. 5. Configure the properties of your ionode4 audio integration device. NOTE: The Connection Mode will be selected depending on the Q-SYS version. Web-Socket with encryption is supported from Q-SYS version 9.8 onwards. nnounce by Simpleway...
- Page 14 8. On successful connection, the status field should say OK. AES67 Receiver Create an AES67 stream in the Q-SYS Designer that matches the network stream set up in the nnounce configuration UI described in the “Network Streams” chapter. nnounce by Simpleway...
- Page 15 IMPORTANT: IP address and port must be configured the same way as in Network streams in the nnounce configuration AES67 Transmitter Create an AES67 stream in the Q-SYS Designer that matches the network stream set up in the nnounce configuration UI described in the “Network Streams” chapter. nnounce by Simpleway...
- Page 16 2. Set up stream properties: 3. Wire the “Input 1” stream to the “Analog output 1 TX” of the ionode4 plugin. IMPORTANT: IP address and port must be configured the same way as in Network streams in the nnounce configuration nnounce by Simpleway...
-
Page 17: Firmware Update
Firmware update of your ionode4 device is available in the Maintenance section. The installation file is provided by the nnounce support team. A. Navigate to the Maintenance section in the left menu. Click on the Update new button in the Firmware update part. nnounce by Simpleway... - Page 18 B. Drag and drop or select the file provided by the nnounce support team. C. Start installing the firmware update. D. Wait for the installation process to complete. E. When the installation process is successfully completed, the login screen will appear. nnounce by Simpleway...
-
Page 19: Installation
IMPORTANT: Please use the supplied connectors for audio and logic connections. Option: Stand-alone Stick the 4 anti-scratch rubber feet to your device. A. Turn your device upside down. B. Take the rubber feet and stick them to the corners of the device. nnounce by Simpleway... - Page 20 Option: Rack mounting The ionode4 can be mounted into a rack as 1. a single unit or 2. as a pair of units attached to each other. 1. Single Two brackets are used to mount a single ionode4 unit: nnounce by Simpleway...
- Page 21 B. Place the bracket as on the picture (use the smaller holes). Use the same screws and attach the bracket to the device. C. Repeat the steps above also for the other device side. nnounce by Simpleway...
- Page 22 For two devices next to each other in the rack, place them in pairs. You will need two brackets and a connection plate with 4 screws. A. Remove two front screws and the middle screw on the device side. B. Repeat step A also for the second ionode4 device just on the other device side. nnounce by Simpleway...
- Page 23 Use the same screws and attach the bracket to the device. Repeat this step also for the second device. D. Turn the devices upside up and place them next to each other as in the picture. nnounce by Simpleway...
- Page 24 – User Guide E. Attach the two devices together with the connection plate using 4 screws. F. Your devices are ready to be mounted in your rack. nnounce by Simpleway...
-
Page 25: Technical Specifications
210 mm (W) x 275 mm (D) x 40 mm (H) 1 510 kg without mounting kit Accessories Mounting kit CONTACT Simpleway North America Headquarters: Simpleway Europe a.s. Address: Address: 1621 Central Avenue Na Okraji 335/42 Cheyenne, Wyoming Prague 6...
