  • Page 1 Operating and installation instructions PKG11 BORA Pro gas glass ceramic cooktop with 2 cooking zones PKG11UMEN-106 1044235 www.bora.com...
  • Page 2 Please accept our apologies in this eventuality. An updated version can be requested from the BORA Service Team. Subject to printing errors and mistakes.
  • Page 3: Table Of Contents

    Warranty, technical service, 5.4.1 Flush installation ..........19 spare parts, accessories 5.4.2 Surface mounting ..........20 10.1 BORA manufacturer’s warranty ......42 Installing the cooktop ........20 10.2 Service .............. 42 5.5.1 Installing the control knob in the 10.3 Spare parts ............42 floor unit front panel .........
  • Page 4: General Information

    INFO BORA Holding GmbH, BORA Vertriebs GmbH & Co KG, BORA APAC Pty Ltd and BORA Lüftungstechnik GmbH - hereinafter referred to as BORA - do not assume any liability for damage Target group arising from non-adherence to these documents...
  • Page 5: Presentation Of Information

    Caution Indicates a potentially hazardous situation which could lead to slight or minor injuries if ignored. — Caution Indicates a situation which could result in material damage if ignored. Tab. 1.2 Meaning of warning symbols and signal words www.bora.com...
  • Page 6: Safety

    Do not place any objects on the operating panel or the cooktop extractor air inlet nozzle. Switch off the appliance after use. Keep pets away from the appliance. Do not use the appliance to heat the room. www.bora.com...
  • Page 7: Safety Instructions - Cooktop Operation

    Switch off the cooktop. still be hot even though there is no Suffocate the fire, for example by indication of residual heat. using a lid. Do not took the cooktop while it is still hot. Keep children away from the hot cooktop. www.bora.com...
  • Page 8 (accident risk). cooktop while it is hot. To choose a suitable stove guard, contact your specialist supplier or DANGER! the BORA Service Team. Risk of explosion from gas! Gas leaks can cause explosions and WARNING! serious injuries. Risk of burns!
  • Page 9: Safety Instructions - Installation

    Do not install any damaged appliance. A damaged appliance may put your safety at risk. Not suitable for installation and operation with aftermarket lids or cover fitted. Repair and maintenance work may only be carried out by specialists authorised by the manufacturer. www.bora.com...
  • Page 10: Safety Instructions - Cleaning And Maintenance

    Plug any leaks immediately. Work on the gas connection may only be carried out by an authorised gas fitter in accordance with applicable legal regulations. Comply with the local regulations of the utility companies. www.bora.com...
  • Page 11: Safety Instructions - Spare Parts

    INFO BORA Holding GmbH, BORA Vertriebs the appliance. GmbH & Co KG, BORA APAC Pty Ltd Do not touch exposed contacts on and BORA Lüftungstechnik GmbH do the electronic unit as they can not assume any liability for damage contain residual charge.
  • Page 12: Technical Data

    550 – 2000 W 61,3 % Total (average) 62,3 % Tab. 3.1 Technical data 14,5 Device dimensions control knob Fig. 3.3 PKG11 Device dimensions front view 10-40 24,5 15,5 Fig. 3.4 PKG11 Device dimensions side view Fig. 3.1 Device dimensions control knob www.bora.com...
  • Page 13: Device Description

    High-power front burner Power display Normal back burner Front cooking zone display Pan support rear Mode or operating mode display Pan support front Rear cooking zone display Control knob for the back hob Control knob for the front hob www.bora.com...
  • Page 14: Functional Principle

    This control ensures that The specifications provided in the table are standard the numerous operating functions of the cooktop can be values. adjusted using the control knobs. The power is controlled via power levels 1 – 9 and P. www.bora.com...
  • Page 15: Power Setting

    55° C After switching it off, the cooking zone remains hot. 70° C appears in the control knob display (residual heat display). The display goes out after a sufficient cooling Tab. 4.5 Heat retention levels time (temperature < 60 °C). www.bora.com...
  • Page 16: Safety Shut-Down

    The activated power setting is switched back to the previous level. The power setting P can no longer be switched on. The set power level is reduced. The cooktop switches off completely. After a sufficient cooling period, the cooktop can be used again in full. www.bora.com...
  • Page 17: Installation

    If there are any missing or damaged parts, please notify BORA After Sales Service immediately. INFO Taking into account the applicable valid Do not under any circumstances install parts which are regulations, the cooktop must be connected to damaged.
  • Page 18: Assembly Instructions

    50 cm² is recommended in or using suitable slatted plinths). the front of the kitchen unit, or an opening cross- The return flow aperture is to be enlarged if necessary. section of at least 150 cm² in the plinth area. www.bora.com...
  • Page 19: Recirculation When Using The Cooktop Extractor In The Recirculation Mode

    + PKAS + air cleaning unit) Gas cooktop PKG11 Fig. 5.6 Cut-out dimensions for flush installation Cooktop extractor PKAS (recirculation) Air cleaning unit (ULB1, ULB3) Recirculation return flow aperture (total opening cross- section ≥1,000 cm² per air cleaning unit) www.bora.com...
  • Page 20: Surface Mounting

    INFO It is recommended to install a mounting rail between adjacent cooktops (mounting rail PZMS available as an accessory). INFO Alternatively, the cooktop can be fitted rotated by 180°. Fig. 5.8 Cut-out dimensions for surface mounting www.bora.com...
  • Page 21: Installing The Control Knob In The Floor Unit Front Panel

    Wave spring Slot the knob ring [3] onto the knob casing [1] and INFO The wave spring must not be used with steel align it to the 12 o’clock position. fronts. The relevant assembly steps should simply be skipped. www.bora.com...
  • Page 22: Installing The Cooktop

    Boreholes for socket (2x external) Bore holes for control knobs (8x) Cooktop (3x) Fig. 5.18 Cooktop and height adjustment plates Cooktop extractor (2x) Worktop Cooktop Floor unit front panel Height adjustment plates If applicable, insert the height adjustment plates [2]. www.bora.com...
  • Page 23: Installation Rotated By 180

    Create the connection between the cooktop and the cooktop extractor. Cooking zone connection INFO According to the default settings, the left control knob operates the front cooking zone and the right control knob operates the rear cooking zone. www.bora.com...
  • Page 24 [4] to the “zone 1” connection on the back of the cooktop [1]. Using the configuration menu, set the correct allocation of the cooking zones in the control knob display (see Configuration menu, 0° or 180° installation). www.bora.com...
  • Page 25: Establishing The Power Connection

    Suitable ventilation measures must be adhered to in be replaced. This may only be done by an authorised particular. member of the After Sales Service team. Always ensure sufficient ventilation during operation Switch off the main switch/automatic circuit breaker (of the appliance). before connecting the cooktop. www.bora.com...
  • Page 26: Gas Connection

    Set the control knob to the 0 position. INFO The gas type and pressure may only be changed Close the gas supply. by a certified engineer or BORA service Switch off the main switch/automatic circuit breaker technician. He/she also assumes responsibility before connecting the cooktop.
  • Page 27: Nozzle Table

    INFO The gas cooktop is set by default to natural gas G20/20mbar (pre-assembled). INFO Use only stamped and approved nozzles. INFO The gas type and pressure may only be changed by a certified engineer or BORA service Fig. 5.27 Cooktop burner with gas burner nozzle technician. He/she also assumes responsibility for the proper gas installation and commissioning.
  • Page 28: Configuration Menu

    INFO Factory setting C 30 Setting the volume of the warning beep Once you have confirmed menu option , you can set the volume of the warning beep. www.bora.com...
  • Page 29: Changing The Set Value

    Installation Setting Characteristic curve INFO The gas type and pressure may only be changed by a certified engineer or BORA service Characteristic curve 1 C 4 0 technician. He/she also assumes responsibility Characteristic curve 2 Factory setting for the proper gas installation and commissioning.
  • Page 30: Exiting The Configuration Menu

    The burner does not ignite and the cooktop does not react. The electronic gas regulator must be recalibrated. Using configuration , reset the gas regulator. C 5 0 The control knob display shows an error message (e.g. E001). Using configuration , reset the gas regulator. C 5 0 www.bora.com...
  • Page 31: Operation

    Bora shall not be held liable for any such damages. INFO If you smell gas or have problems with the gas 6.1.2 Using the gas cooktop...
  • Page 32: Using The Gas Cooktop With A Cooktop Extractor

    INFO If it does not ignite, a beep will be heard and the Avoid using a high power level on the cooktop power level display will flash. extractor when the gas cooktop is set to a low power level. www.bora.com...
  • Page 33: Switching On The Cooking Zone

    The temperature information can also vary due to the influence of the cooktop extractor. www.bora.com...
  • Page 34: Childproofing Feature

    Switching the timer off early: The childproofing feature is only deactivated for this Turn the knob ring to the 12 o’clock position. cooking session and you can set the desired power The control knob display changes to , a beep sounds level. www.bora.com...
  • Page 35: Pause Function

    Deactivating the pause function Press the touch surface of the control knob for 1 second. A beep sounds and the power level selected is shown on the control knob display. The cooking session continues. www.bora.com...
  • Page 36: Cleaning And Maintenance

    Keep the cooktop clean. damp cloth. These spots are normal and do not Remove any dirt immediately. constitute an impairment Only use cookware suitable for glass ceramic cooktops (see Appliance description chapter). www.bora.com...
  • Page 37: Cleaning The Pan Supports

    Finally, dry the pan supports carefully with a clean so it fits perfectly, taking into account the positioning cloth. aids [4]. Before reassembling the flame openings, burner heads and burner caps must be completely dry. Put the burner parts back together again. www.bora.com...
  • Page 38: Cleaning The Control Knobs

    7.4.2 Cleaning the touch surface and the knob housing Remove the knob ring. Clean the touch surface and the knob housing with a soft, damp cloth. Dry the touch surface and the knob housing carefully. Place the knob ring back on the knob housing. www.bora.com...
  • Page 39: Troubleshooting

    If necessary, contact a is defective or has been triggered. specialist electrician. The fuse or the automatic circuit breaker Contact the BORA Service Team. trips several times. The power supply is disconnected. Have a specialist electrician inspect the power supply.
  • Page 40 After resolving the fault, turn the knob ring to the 12 o’clock position (0 position). In all other cases, contact the BORA Service Team (see Warranty, technical service and spare parts chapter) and enter the error number displayed and the device type.
  • Page 41: Decommissioning, Disassembly And Disposal

    Remove the silicone joints. components and other materials. Remove the device from the worktop by lifting it upwards. Remove any other accessories. Dispose of the old device and any contaminated accessories as described under “ Environmentally- friendly disposal”. www.bora.com...
  • Page 42: Warranty, Technical Service, Spare Parts, Accessories

    In order to file a warranty claim, the end customer is to The BORA Service Team will require the type designation notify their dealer or BORA of the fault and must present and serial number of your device (FD number).
  • Page 43: Accessories

    BORA gas nozzle set natural gas G20/25 mbar PKGDS2025 BORA gas nozzle set natural gas G20/10 mbar PKGDS2010 BORA gas nozzle set liquid gas G30/G31 50 mbar PKGDS3050 BORA Pro gas nozzle set liquid gas G31/G30 mbar PKGDS3130 BORA gas nozzle set liquid gas G30/G31 28-30 mbar...
  • Page 44 F +49 (0) 8035 / 9840-300 F +43 (0) 5373 / 62250-90 info@bora.com mail@bora.com www.bora.com www.bora.com Austria: Australia - New Zealand: BORA Vertriebs GmbH & Co KG BORA APAC Pty Ltd Innstraße 1 100 Victoria Road 6342 Niederndorf Drummoyne NSW 2047 Austria Australia...
