- Page 1 Operating and installation instructions PKG11 BORA Pro gas glass ceramic cooktop with 2 cooking zones PKG11UMEN-103 1041667 www.bora.com...
- Page 2 Please accept our apologies in this eventuality. An updated version can be requested from the BORA Service Team. Subject to printing errors and mistakes.
-
Page 3: Table Of Contents
5.3.1 Safety clearances ..........18 5.3.2 Worktop and kitchen units ........ 18 and disposal 5.3.3 Gas cooktop air supply PKG11 ......18 Decommissioning ..........40 5.3.4 Recirculation when using the cooktop Disassembly ............40 extractor in the recirculation mode ....19 Environmentally-friendly disposal ......40... -
Page 4: General Information
INFO BORA Holding GmbH, BORA Vertriebs GmbH & Co KG, BORA APAC Pty Ltd and BORA Lüftungstechnik GmbH - hereinafter referred to as BORA - do not assume any liability for damage Target group arising from non-adherence to these documents... -
Page 5: Presentation Of Information
Caution Indicates a potentially hazardous situation which could lead to slight or minor injuries if ignored. — Caution Indicates a situation which could result in material damage if ignored. Tab. 1.2 Meaning of warning symbols and signal words www.bora.com... -
Page 6: Safety
Do not store any items that could be of inte- rest to children in storage spaces above or behind the appliance. Otherwise, they will be tempted to climb onto the appliance. www.bora.com... -
Page 7: Safety Instructions - Operation
DANGER! Risk of explosion from gas! Gas leaks can cause explosions and serious injuries. Keep ignition sources (naked flames, heaters) away. Close the gas supply and turn off the mains supply. www.bora.com... - Page 8 Do not place any items on the cook- Keep children away from the cook- top. top when it is hot or ensure they are Please use suitable tools (pot hol- supervised at all times. ders, oven gloves). www.bora.com...
-
Page 9: Safety Instructions - Installation
To choose a suitable stove guard, A damaged glass ceramic panel can contact your specialist supplier or cause injuries. the BORA Service Team. Do not touch the surface of the ap- pliance. WARNING! Switch off all burners and electrical Risk of burns! heating elements immediately. -
Page 10: Safety Instructions - Disassembly And Disposal
Plug any leaks immediately. electric shock. Securely disconnect the appliance from the mains using LS switches, fuses, automatic circuit breakers or contactors. Use an authorised measuring device to ensure that there is no power to the appliance. www.bora.com... -
Page 11: Safety Instructions - Spare Parts
Safety DANGER! INFO BORA Holding GmbH, BORA Vertriebs Risk of asphyxiation! GmbH & Co KG, BORA APAC Pty Ltd Packaging components (e.g. film, and BORA Lüftungstechnik GmbH do polystyrene) can be life-threatening for not assume any liability for damage ari- children. -
Page 12: Technical Data
Heat retention levels High-power front burner 800 – 3000 W Normal back burner 550 – 2000 W Fig. 3.2 PKG11 Device dimensions aerial view Total nominal connection values 4,80 kW G30/50 mbar: 328 g/h Total nominal connection values 5,00 kW G20/20 mbar: 0,449 m³/h... -
Page 13: Device Description
Power display High-power front burner Front cooking zone display Normal back burner Mode or operating mode display Pan support rear Rear cooking zone display Pan support front Control knob for the back hob Control knob for the front hob www.bora.com... -
Page 14: Functional Principle
This control ensures that The specifications provided in the table are standard the numerous operating functions of the cooktop can be values. adjusted using the control knobs. The power is controlled via power levels 1 – 9 and P. www.bora.com... -
Page 15: Automatic Heat Up Function
After switching it off, the cooking zone remains hot. can also vary due to the influence of the cooktop appears in the control knob display (residual heat extractor. display). The display goes out after a sufficient cooling time (temperature < 60 °C). www.bora.com... -
Page 16: Safety Shut-Down
The power setting P can no longer be switched on. The power level set is reduced. The cooktop switches off completely. After a sufficient cooling period, the cooktop can be used again in full. www.bora.com... -
Page 17: Installation
If there are any missing or damaged parts, please notify BORA After Sales Service immediately. INFO Taking into account the applicable valid Do not under any circumstances install parts which are regulations, the cooktop must be connected to damaged. -
Page 18: Assembly Instructions
Installation Assembly instructions 5.3.3 Gas cooktop air supply PKG11 5.3.1 Safety clearances Maintain the following safety clearances: Fig. 5.2 Front air supply Air supply via the front of the body (opening cross-section ≥ 50 cm²) Optional cable protection (shortened) Fig. 5.1... -
Page 19: Recirculation When Using The Cooktop Extractor In The Recirculation Mode
A ±2 B ±2 Fig. 5.6 Cut-out dimensions for flush installation Fig. 5.4 Recirculation design example (kitchen island + PKG11 + PKAS + air cleaning unit) Gas cooktop PKG11 Cooktop extractor PKAS (recirculation) Air cleaning unit (ULB1, ULB3) Recirculation return flow aperture (total opening cross- section ≥1,000 cm²... -
Page 20: Surface Mounting
5.5.1 Installing the control knob in the floor unit front panel Fig. 5.8 Cut-out dimensions for surface mounting INFO Pre-drill the bore holes to prevent tearing out the fixed front panel. Fig. 5.9 Surface mounting cut-out Fig. 5.10 Installed control knob and cooktop www.bora.com... - Page 21 Use the marking to align the control knob vertically in the 12 o’clock position. Boreholes for socket (2x external) Tighten the fixing nut. Bore holes for control knobs (8x) Slot the knob ring onto the control knob. Cooktop (3x) Cooktop extractor (2x) Worktop Floor unit front panel www.bora.com...
-
Page 22: Installing The Cooktop
INFO Cables of sufficient length are provided. Fig. 5.16 Cooktop and height adjustment plates Cooktop Height adjustment plates If applicable, insert the height adjustment plates [2]. www.bora.com... -
Page 23: Sealing The Cooktop
Connect the connection on the back of the left control knob [5] to the “zone 1” connection on the front of the cooktop [1]. Fig. 5.20 Connection on the rear of the control knob Connection on the rear of the control knob www.bora.com... -
Page 24: Establishing The Power Connection
(see Configuration menu, 0° or 180° chapter). installation). Check that all the functions are working correctly. Connecting the automatic extraction system Connect the cooktop extractor to the cooktop using the connector provided for the automatic extraction system. www.bora.com... -
Page 25: Gas Installation
Shut off the gas supply to the gas supply pipe. (see table 6.2 Connection bracket). Switch off the main switch/automatic circuit breaker. Secure the main switch/automatic circuit breaker against being switched back on without permission. Make sure the power to the appliance is disconnected. www.bora.com... -
Page 26: Nozzle Table
Screw on the corresponding nozzle for the gas type to G31/30mbar / 4,90 kW / 348g/h / 0,183 m³/h be used into the gas burner [2]. Put the burner parts back together again. Position the burner head [2] correctly on the gas outlet. www.bora.com... -
Page 27: Configuration Menu
C 23 INFO In the three-character combination shown, the INFO For installation rotated by 180°, the setting C 2 1 right-hand figure shows the value saved in the correctly assigns the correct cooking zones inside system. the control knob display. www.bora.com... -
Page 28: Changing The Set Value
INFO The characteristic curve may only be adjusted by INFO Factory setting a certified engineer or BORA service technician. C 30 INFO The gas type and pressure may only be changed Setting... -
Page 29: Exiting The Configuration Menu
The burner does not ignite and the cooktop does not react. The electronic gas regulator must be recalibrated. Using configuration , reset the gas regulator. C 5 0 The control knob display shows an error message (e.g. E001). Using configuration , reset the gas regulator. C 5 0 www.bora.com... -
Page 30: Operation
Bora shall not be held liable for any such damages. INFO If you smell gas or have problems with the gas 6.1.2 Using the gas cooktop... -
Page 31: Using The Gas Cooktop With A Cooktop Extractor
Avoid using a high power level on the cooktop INFO If it does not ignite, a beep will be heard and the extractor when the gas cooktop is set to a low power power level display will flash. level. www.bora.com... -
Page 32: Switching On The Cooking Zone
The temperature information can also vary due to the influence of the cooktop extractor. www.bora.com... -
Page 33: Childproofing Feature
Switching the timer off early: The childproofing feature is only deactivated for this Turn the knob ring to the 12 o’clock position. cooking session and you can set the desired power The control knob display changes to , a beep sounds level. www.bora.com... -
Page 34: Pause Function
INFO If the control knob display shows , the cooking zone is still hot. Fig. 6.4 Switching off the cooking zone Turn the knob ring to the 12 o’clock position A beep sounds and the cooking zone is deactivated. www.bora.com... -
Page 35: Cleaning And Maintenance
Keep the cooktop clean. points, which can be easily removed with a Remove any dirt immediately. damp cloth. These spots are normal and do not Only use cookware suitable for glass ceramic cooktops constitute an impairment (see Appliance description chapter). www.bora.com... -
Page 36: Cleaning The Pan Supports
Finally, dry the pan supports carefully with a clean so it fits perfectly, taking into account the positioning cloth. aids [4]. Before reassembling the flame openings, burner heads and burner caps must be completely dry. Put the burner parts back together again. www.bora.com... -
Page 37: Cleaning The Control Knobs
Rinse the knob ring well after cleaning. Dry the knob ring carefully. Place the dry knob ring back on the knob housing. Make sure it is positioned correctly (0 position). If necessary, turn the knob ring to the 12 o’clock position (= 0 position). www.bora.com... -
Page 38: Troubleshooting
If necessary, contact a is defective or has been triggered. specialist electrician. The fuse or the automatic circuit breaker Contact the BORA Service Team. trips several times. The power supply is disconnected. Have a specialist electrician inspect the power supply. - Page 39 After resolving the fault, turn the knob ring to the 12 o’clock position (0 position). In all other cases, contact the BORA Service Team (see Warranty, technical service and spare parts chapter) and enter the error number displayed and the device type.
-
Page 40: Decommissioning, Disassembly And Disposal
Remove the silicone joints. components and other materials. Remove the device from the worktop by lifting it upwards. Remove any other accessories. Dispose of the old device and any contaminated accessories as described under “ Environmentally- friendly disposal”. www.bora.com... -
Page 41: Warranty, Technical Service, Spare Parts, Accessories
10 Warranty, technical 10.3 Spare parts service, spare parts, Only use original spare parts for repairs. Repairs may only be carried out by the BORA Service accessories Team. INFO Spare parts can be obtained from your BORA Observe all safety and warning information (see the dealer, the BORA online service website at www. -
Page 42: Notes
Notes 11 Notes www.bora.com... - Page 44 F +49 (0) 8035 / 9840-300 F +61 2 8076 3514 info@bora.com info@boraapac.com.au www.bora.com www.bora-australia.com.au Austria: BORA Vertriebs GmbH & Co KG Innstraße 1 6342 Niederndorf Austria T +43 (0) 5373 / 62250-0 F +43 (0) 5373 / 62250-90 mail@bora.com www.bora.com...
