OPERATING INSTRUCTIONS
Electronic digital position indicators
DD52R-E-RF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DD52R-E-RF and is the answer not in the manual?

Questions and answers

Related Manuals for Elesa DD52R-E-RF

Summary of Contents for Elesa DD52R-E-RF

  • Page 1 OPERATING INSTRUCTIONS Electronic digital position indicators DD52R-E-RF...

  • Page 2: Table Of Contents

    These operating instructions are valid for the following products: CE.99203-W2 DD52R-E-RF-W2-SST-F.20-IP65-C1 CE999203-W2 DD52R-E-RF-W2-SST-F.3/4-IP65-C1 CE.99202-W2 DD52R-E-RF-W2-SST-F.20-IP65-C2 CE999202-W2 DD52R-E-RF-W2-SST-F.3/4-IP65-C2 CE.99201-W2 DD52R-E-RF-W2-SST-F.20-IP65-C3 CE999201-W2 DD52R-E-RF-W2-SST-F.3/4-IP65-C3 CE999205-W2 DD52R-E-RF-W2-SST-F.3/4-IP65-C55 CE.99205-W2 DD52R-E-RF-W2-SST-F .20-IP65-C55 CE999213-W2 DD52R-E-RF-W2-SST-F.3/4-IP67-C1 CE.99213-W2 DD52R-E-RF-W2-SST-F .20-IP67-C1 CE999212-W2 DD52R-E-RF-W2-SST-F.3/4-IP67-C2 CE.99212-W2 DD52R-E-RF-W2-SST-F .20-IP67-C2 CE999211-W2 DD52R-E-RF-W2-SST-F.3/4-IP67-C3 CE.99211-W2 DD52R-E-RF-W2-SST-F .20-IP67-C3 CE999215-W2 DD52R-E-RF-W2-SST-F.3/4-IP67-C55 CE.99215-W2 DD52R-E-RF-W2-SST-F .20-IP67-C55...
  • Page 3 DD52R-E-RF Electronic digital position indicators 8.8.3 Direct access to target rogramming and/or loading 8.8.4 Indications for reaching the target position 8.8.5 Disabling the target 8.8.6 Display in target mode 9. RF functionalities 9.1 Device ID 9.2 Binding 9.3 Heartbeat 9.4 Targets 9.5 RF communication quality...

  • Page 4: Safety Instructions

    DD52R-E-RF Electronic digital position indicators 1. Safety Instructions This device has been designed and manufactured in accordance with current legislation. To keep the product in this state, it must be assembled and used correctly, in strict compliance with the instructions contained in this instruction manual and with the following specific safety precautions.

  • Page 5: Version And Functionality

    In case of specific need, it is recommended to ask the Elesa service staff for assistance. Elesa reserves the right, without further communication, to make improvements, additions, corrections to the menu items, that do not modify or affect the described functionality of the product but are necessary for the continuous improvement to which these products are subjected.
  • Page 6 > 20 ° C and <30°C and default setup. Furthermore, this value refers to the condition of the device when it leaves the Elesa factory. Long storage times must always be considered for the estimation of the battery life when the device becomes operational.

  • Page 7: Installation

    DD52R-E-RF Electronic digital position indicators 4. Installation 1.Drill a Ø 6x10 mm hole in the machine body with a 30 mm centre distance from the shaft for mounting the rear reference pin. device 2. Mount the on the shaft and make sure the reference pin fits into the hole.
  • Page 8 DD52R-E-RF Electronic digital position indicators Key Or Key Operating Programming Combination Mode Mode Select the item Keep pressed for 3 sec menu or confirm to enter the Programming Mode: during the selection or pressing, the word "Fooo" appears on the display...
  • Page 9 DD52R-E-RF Electronic digital position indicators Key Or Key Operating Programming Combination Mode Mode While entering the numerical value of a parameter: Short press: decreases the selected digit by one with each Switch between measure press. mode: Press and hold: It is possible to choose...
  • Page 10 DD52R-E-RF Electronic digital position indicators Key Or Key Operating Programming Combination Mode Mode Programmable for one of the following functions (see menu item – 0 _ _ _ _ 0 chap.10.3): [DEFAULT]: P_OrG shows and allows you to set the OriGin parameter.

  • Page 11: Switching On/Off The Device

    DD52R-E-RF Electronic digital position indicators Key Or Key Operating Programming Combination Mode Mode Programmable for one of the following functions (see menu item _ _ _ 0 _ 0 – chap.10.3): tArGEt : the key combination allows to load / program one of the 32 target positions (see chap.10.4)

  • Page 12: Operational Mode

    DD52R-E-RF Electronic digital position indicators 8. Operational mode 8.1 Reference points, origin and offset When the device is turned on or reset, the position of the shaft at that moment is set as the origin of the measure. The value attributed to this position is given by the parameters, Origin and Offset, which can be set by the user.

  • Page 13: Resolution

    DD52R-E-RF Electronic digital position indicators 8.2 Resolution The device manages different measure display resolution values for each of the three units of measure managed (mm, inch and degrees). The same display resolution set is used to set different parameters such as Origin, offsets and targets.

  • Page 14: Internal Reference Point Reset

    DD52R-E-RF Electronic digital position indicators The selected measure mode is indicated on the display by the symbols: - mm : millimeters - INCH : inches - D : degrees It is possible to change the function of the 0 _ _ _ _ _...

  • Page 15: Direct Programming Of Origin, Offset And Step Parameters

    DD52R-E-RF Electronic digital position indicators - L_OFFS (DEFAULT): the key combination allows you to select an offset . - SEtOrG: the key combination allows to reset the origin (see chap. 7.5). - OFF : the key combination is disabled. This function is available only in absolute WARNING measure mode.

  • Page 16: Targets

    (mm and inch) and for degrees measurements. 8.8 Targets The DD52R-E-RF permits you to set up to 32 target positions allowing you to store any relevant and frequently used settings. 8.8.1 Programming the targets To program the targets: - activate the Programming Mode - select tArGEt in the main menu (see chap.

  • Page 17: Direct Access To Target Rogramming And/Or Loading

    DD52R-E-RF Electronic digital position indicators 8.8.3 Direct access to target programming and/ or loading The key combination allows, if enabled, direct access to target programming or loading. It is possible to change the function of the key by _ _ _ 0 _ 0...

  • Page 18: Disabling The Target

    DD52R-E-RF Electronic digital position indicators 8.8.5 Disabling the target If a Target mode is active, it can be cancelled pressing the will appear the option. Press the key StoPt to confirm the return to Operational mode, otherwise press the key to cancel.

  • Page 19: Rf Functionalities

    DD52R-E-RF Electronic digital position indicators 9. RF functionalities The DD52R-E-RF is compatible with Elesa wireless network which allows meters and electronic indicators to communicate via radio with a PLC. Elesa wireless network is made by the following components: - One control unit UC-RF DD51-E-RF , DD52R-E-RF o MPI-R10-RF .

  • Page 20: Binding

    DD52R-E-RF Electronic digital position indicators 9.2 Binding The Device Id allows to recognize the online device and create a stable communication link with a UC-RF . The operation that allows this association is called Binding. A device is born not associated with any UC-RF (unbound).

  • Page 21: Targets

    As a result, battery life is strongly influenced by the set HB frequencies. 9.4 Targets Using the DD52R-E-RF , the target positions can be sent from the PLC to the via the UC-RF control unit. When a target is device transmitted, it behaves in the same way described in chap.

  • Page 22: Programming Mode

    DD52R-E-RF Electronic digital position indicators 10. Programming mode In Operational Mod press the key p for 3 seconds to access Programming mode. Depending on the setting of the PASS parameter (see chap. 8.5.4), the system may ask for a password to be entered. Press the key...

  • Page 23: Programmable Parameters (In Alphabetical Order)

    DD52R-E-RF Electronic digital position indicators confirmed parameter is different from the one currently stored, the display will show the message CHAnGd . WARNING: To cancel the entry, keep the key pressed until the writing CAnCEL appears and you exit the value entry mode.
  • Page 24 DD52R-E-RF Electronic digital position indicators Parameter Description Available options Default Heart beat Update frequency of radio readings:0÷7 rate 126.95ms HbFrAt 253.9 ms 380.85 ms … …. 1015.6 ms Heart beat auto ON – OFF HBAUp update Offset It is possible to store up to 10...
  • Page 25 DD52R-E-RF Electronic digital position indicators Parameter Description Available options Default Resolution Depending on the unit of 0.01 of the measurement, the displayed permitted values are: ches: measure 1 ; 0.1 ; 0.01 0.001 inches: 1 ; 0.1 ; 0.01 ; 0.001...

  • Page 26: Main Menu Tree

    DD52R-E-RF Electronic digital position indicators Parameter Description Available options Default Target It is possible to store up to 32 Target positions. positions The settable values depend on the resolution set as follows: tArGEt Res = 1 : -199999 ÷ 999999 Res = 0.1 : -19999.9 ÷...
  • Page 27 DD52R-E-RF Electronic digital position indicators 0° diSPL 180° SPEEd 1000 See chap. 10.5 rAdio 0.01 ÷ 9.99 P_toLL 0.001 ÷ 0.393 inch degrees 0.01÷9.99 tArGEt See chap. 8.4 0 _ _ _ _ _ nodEG ArCLr _ _ 0 _ _ _...

  • Page 28: Target Menu Tree

    DD52R-E-RF Electronic digital position indicators Target menu tree 10.4 LtG 00 LOAd_t LtG 31 -199999 ÷ 999999 PtG 00 PrOG_t -199999 ÷ 999999 PtG 31 The values must be divided by the number of decimal places of the resolution set.

  • Page 29: Lcd Test

    Id. In case of need for support, the data in the Info menu must be noted and provided to Elesa Models all rights reserved in accordance with the law. Always mention...

  • Page 30: Password

    DD52R-E-RF Electronic digital position indicators 10.6.4 Password You can avoid unwanted access to the device menu by choosing “ on “ in the PASS menu item. By default the password is set to: 22011. It is possible to change the password by selecting the Set option from the Password menu.

  • Page 31: Common Problems And Solutions

    DD52R-E-RF Electronic digital position indicators 12. Common problems and solutions Message on Description Action the display In Operational mode, the device continues to correctly measure the position of the shaft. If the measured value is within the capacity of the display, it will be shown correctly.
  • Page 32 DD52R-E-RF Electronic digital position indicators EU DECLARATION OF CONFORMITY (DoC) COMPANY NAME: Elesa S.p.a. POSTAL ADDRESS: Via Pompei 29 POSTCODE AND CITY: 20900 Monza TELEPHONE NUMBER: +39 039 28111 E-MAIL ADDRESS: info@elesa.com Declare that the DoC is issued under our sole responsibility and...
  • Page 33 The Company Elesa S.p.A. can neither be held legally responsible nor liable for lacking or incorrect information and the ensuing consequences. The Company Elesa S.p.A. reserves the right to alter or improve the or parts of them and/ electronic position indicators or the enclosed brochures without prior notice ELESA S.p.A.
