Setting and Monitoring a Safety Input
Explicit
message
Terminal
Maintenance
Information
Monitor Mode
Input Set Val-
ue for Total
ON Time or
Contact Oper-
ation Counter
Input Total
ON Time or
Contact Oper-
ation Counter
Read
Input Total
ON Time or
Contact Oper-
ation Counter
Reset
A-2 Explicit Messages
Read/ Function Command
write
Service
Code
Read Reads the monitor 0E hex
mode for mainte-
nance information
of the input (1 to
12) specified by
the instance ID.
Write Writes the monitor 10 hex
mode for mainte-
nance information
of the input (1 to
12) specified by
the instance ID.
Read Reads the set val- 0E hex
ue for the total ON
time (unit: s) or
number of contact
operations (unit:
operations) of the
input (1 to 12)
specified by the
instance ID.
Write Writes the set 10 hex
value for the total
ON time (unit: s) or
number of contact
operations (unit:
operations) of the
input (1 to 12)
specified by the
instance ID.
Read Reads the set 0E hex
value for the total
ON time (unit: s) or
number of contact
operations (unit:
operations) of the
input (1 to 12)
specified by the
instance ID.
Reset Resets the total 05 hex
ON time or number
of contact opera-
tions (unit: opera-
tions) for time input
(1 to 32) specified
by the instance ID.
Class ID Instance Attribute
ID ID
3D hex 01 to 0C 65 hex
hex
3D hex 01 to 0C 65 hex
hex
3D hex 01 to 0C 68 hex
hex
3D hex 01 to 0C 68 hex
hex
3D hex 01 to 0C 66 hex
hex
3D hex 01 to 0C 66 hex
hex
Response
Data size
1 byte
00 hex:
Total ON time
mode
01 hex: Contact
operation counter
mode
1 byte 00 hex:
Total ON time
mode 01 hex:
Contact opera-
tion counter
mode
4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
4 bytes 0000
0000 to FFFF
FFFF hex (0 to
4,294,967,295)
4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
