Explicit Messages - Omron DEVICENET SAFETY - 04-2005 Operation Manual

Error Codes
Code
08FF
09FF
16FF
15FF
13FF
0CFF
20FF
0EFF
10FF
14FF
19FF
2AFF
A-2

Explicit Messages

Reading General Status
Explicit
message
General Sta-
tus Read
Setting and Monitoring the Unit Conduction Time
Explicit
message
Unit Mainte-
nance Set
Value
Unit Mainte-
nance
Present Value
Unit Mainte-
nance Flag
90
Error name
Service not supported
Invalid attribute value
Object does not exist
Too much data
Not enough data
Object state conflict
Invalid parameter
Attribute not settable
Device state conflict
Attribute not supported
Store operation failure
Group 2 only server general
failure
Read/ Function Command
write
Service
code
Read Reads the 0E hex
specified slave's
status flags (8 bits)
Read/ Function Command
write
Service
Code
Read Reads the set val- 0E hex
ue for the Unit
Conduction Time
(unit: 0.1 h).
Write Writes the set val- 10 hex
uefor the Unit
Conduction Time
(unit: 0.1 h).
Read Reads the present 0E hex
value for the Unit
Conduction Time
(unit: 0.1 h).
Read Reads the monitor 0E hex
status of Unit
Conduction Time.
Cause
The service code is incorrect.
The specified attribute value is not supported. The data
written was outside the valid range.
The specified Instance ID is not supported.
The data is larger than the specified size.
The data is smaller than the specified size.
The specified command cannot be executed due to an
internal error.
The specified operation command data is not supported.
An attribute ID supported only for reading has been exe-
cuted for a write service code.
The specified command cannot be executed due to an
internal error.
The specified attribute is not supported.
The data cannot be stored in memory.
The specified command or attribute is not supported or
the attribute was not set.
Class ID Instance Attribute
ID ID
95 hex 01 hex 65 hex
Class ID Instance Attribute
ID ID
95 hex 01 hex 73 hex
95 hex 01 hex 73 hex
95 hex 01 hex 71 hex
95 hex 01 hex 72 hex
A DeviceNet Explicit Messages
Response
Data size
- 1 byte
Response
Data size
- 4 bytes
0000 0000 to
FFFF FFFF hex (0
to 4,294,967,295)
4 bytes
0000 0000 to
FFFF FFFF hex
(0 to
4,294,967,295)
4 bytes
0000 0000 to
FFFF FFFF hex (0
to 4,294,967,295)
1 byte
00 hex: Within
range
01 hex: Over
range (over the
monitor value)
