CD Automation REVEX 1PH User Manual page 40

REVEX
1PH from 60A to 90A
Parameter Name
Analog In1
Indicates the percent of full scale measured
by analog input 1
Analog In2
Indicates the percent of full scale measured
by analog input 2
SW Ver
Indicates the software version number (x.xx.x)
SW Rel Indicates the software release date year and
week (yyww)
Unit Type
Indicates the type of power controller
Parameter Name
Max Voltage Indicates the maximum voltage rating of the
power controller
Max Current
Indicates the maximum current capacity of
the power controller
Aux Voltage
Indicates the measured line voltage
Serial No
Indicates the serial number of the power
controller
SCR Temp Indicates whether the SCR is below or above
the factory-set trip point
Description
Option
RC 1
Single Phase
RC 2
Two Leg, three phase
RC 3
Three Leg, three phase
RC 3P
Three Leg, three phase with phase angle capability
Description
Option
Disabled No sensor present / temperature below limit
Over Temp Over temperature
Range
0 to 100.0
0 to 100.0
0 to 65535
0 to 65535
Description
Range
0 to 1023
0 to 9999
0 to 1023
0 to 9999
Description
40
User's manual
Modbus
Par.
Unit
Address Type
Read
% 138
Only
Read
% 137
Only
Read
48
Only
Read
49
Only
Read
36
Only
Value
7
8
9
9999
Modbus
Par.
Unit
Address Type
Read
V 41
Only
Read
A 62
Only
Read
V 43
Only
149-150 Read
151-152 Only
Read
127
Only
Value
0
130
