CD Automation REVEX 1PH User Manual page 33

REVEX
1PH from 60A to 90A
Parameter Name
Feedback
Choose the feed-back type
Parameter Name
Set the gain for the main loop. A larger
Pb Power
value yields a larger adjustment for a
given deviation
Set how aggressively the integral part
Ti Power
of the control algorithm acts. A larger
settings yields a larger adjustment for
a given deviation over a given time
Set the gain for the current loop. A
Pb Current
larger value yields a larger adjustment
for a given deviation
Set how aggressively the integral acts
Ti Current
in the current loop. A larger settings
yields a larger adjustment for a given
deviation over a given time
Set the threshold of resistance that
HB Sense
activates the Heater Break alarm. This
setting is in percentage of the nominal
load resistance
Description
Option
V²
Voltage squared
None
No feed-back
I²
Current squared
Voltage
Voltage
Current
Current
Power
Power
External
External signal via analog input 2
DEFAULT: None
Description
Default Range
1
Description
Default Range
10% 0 to 255
50 0 to 255
10% 0 to 255
50 0 to 255
100% 0 to 100.0
33
User's manual
Modbus
Par.
Unit
Address Type
Read
19
Write
Value
0
1
2
32
64
128
256
1
Modbus
Par.
Unit
Address Type
Read
% 26
Write
Read
27
Write
Read
% 63
Write
Read
64
Write
Read
% 29
Write
