Structured Text (ST Language) Specifications
Statement
EXIT
RETURN
Operators
Operation
Parentheses and (expression),
brackets array[index]
Function evaluation identifier
Exponential **
Complement NOT
Multiplication *
Division /
Addition +
−
Subtraction
Comparisons <, >, <=, >=
Equality =
Non-equality <>
Boolean AND &
Boolean AND AND
Boolean exclusive XOR
OR
Boolean OR OR
Note Operations are performed according to the data type.
Therefore, the addition result for INT data, for example, must be a variable using the INT data type. Par-
ticularly care is required when a carry or borrow occurs in an operation for integer type variables. For
example, using integer type variables A=3 and B= 2, if the operation (A/B)*2 is performed, the result of
A/B is 1 (1.5 with the value below the decimal discarded), so (A/B)*2 = 2.
Functions
Function
Numerical Functions
Arithmetic Functions
Data type conversion Functions
142
Stops repeated processing.
Returns to the point in the program
from which a function block was called.
Symbol Data types supported by operator
Depends on the function (refer to 2-6 Instruction
Support and Operand Restrictions)
REAL, LREAL
BOOL, WORD, DWORD, LWORD
INT, DINT, UINT, UDINT, ULINT, REAL, LREAL
INT, DINT, LINT, UINT, UDINT, ULINT, REAL, LREAL 5
INT, DINT, LINT, UINT, UDINT, ULINT, REAL, LREAL 6
INT, DINT, LINT, UINT, UDINT, ULINT, REAL, LREAL 6
BOOL, INT, DINT, LINT, UINT, UDINT, ULINT,
WORD, DWORD, LWORD, REAL, LREAL
BOOL, INT, DINT, LINT, UINT, UDINT, ULINT,
WORD, DWORD, LWORD, REAL, LREAL
BOOL, INT, DINT, LINT, UINT, UDINT, ULINT,
WORD, DWORD, LWORD, REAL, LREAL
BOOL, WORD, DWORD, LWORD
BOOL, WORD, DWORD, LWORD
BOOL, WORD, DWORD, LWORD
BOOL, WORD, DWORD, LWORD
Absolute values, trigonometric functions, etc.
Exponential (EXPT)
Source data type_TO_New data type (Variable name)
Function
EXIT;
RETURN;
Syntax
Appendix B
Example
Priority
1: Lowest
11: Highest
1
2
3
4
5
7
8
8
9
9
10
11
