Operating Specifications - Omron CX-PROGRAMMER 5.0-FUNCTION BLOCK OPERATION Operation Manual

Instance Specifications
Input Contents
variable
data type
UINT Unsigned integer
UDINT Unsigned double integer
ULINT Unsigned long (8-byte)
integer
REAL Real number
LREAL Long real number
WORD 16-bit data
DWORD 32-bit data
LWORD 64-bit data
2-2-3

Operating Specifications

Calling Instances
Size Parameter value input
16 bits Positive value: & or + followed
by integer
32 bits
64 bits
32 bits Positive value: & or + followed
by real number (with decimal
point)
Negative value:
64 bits
real number (with decimal
point)
16 bits # followed by hexadecimal
number (4 digits max.)
& or + followed by decimal
number
32 bits # followed by hexadecimal
number (8 digits max.)
& or + followed by decimal
number
64 bits # followed by hexadecimal
number (16 digits max.)
& or + followed by decimal
number
(2) The size of function block input variables and output variables must
match the size of program symbols (global and local), as shown in the fol-
lowing table.
Size Function block variable data
1 bit BOOL
16 bits INT, UINT, WORD
32 bits DINT, UDINT, REAL, DWORD
64 bits LINT, ULINT, LREAL, LWORD
More than 1 Non-boolean
bit
Note The program symbol NUMBER can be set only in the input param-
eters. The value that is input must be within the size range for the
function block variable data type.
The user can call an instance from any location. The instance will be executed
when the input to EN is ON.
Instance
1.0
0.0
EN ENO
D0 D10
A B
method
&0 to 65,535
&0 to 4,294,967,295
&0 to 18,446,744,073,709,551,615
−3.402823 × 10
− 38
10
3.402823 × 10
−
followed by
−1.79769313486232 × 10
−2.22507385850720 × 10
2.22507385850720 × 10
1.79769313486232 × 10
#0000 to FFFF or &0 to 65,535
#00000000 to FFFFFFFF or &0 to
4,294,967,295
#0000000000000000 to
FFFFFFFFFFFFFFFF or &0 to
18,446,744,073,709,551,615
Program symbol (global, local)
type
BOOL
INT, UINT, UINT BCD, WORD
DINT, UDINT, UDINT BCD, REAL,
DWORD
LINT, ULINT, ULINT BCD, LREAL,
LWORD
CHANNEL, NUMBER (see note)
In this case, the input to EN is bit 0.0 at the left of the diagram.
• When the input to EN is ON, the instance is executed and
the execution results are reflected in bit 1.0 and word D10.
• When the input to EN is OFF, the instance is not executed,
bit 1.0 is turned OFF, and the content of D10 is not changed.
Section 2-2
Setting range
38 to −1.175494 ×
− 38
, 0, 1.175494 × 10
to
38
308
to
− 308
, 0,
− 308
,
308
data type
35
